2.4

Ai Tweaker menu

The Ai Tweaker menu items allow you to configure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field
values can cause the system to malfunction.
The configuration options for this section vary depending on the CPU and DIMM model you
installed on the motherboard.
EFI BIOS Utility - Advanced Mode
Main
Target DRAM Speed: 1333MHz
Memory Frequency
iGPU Max. Frequency
> GPU Boost
> DRAM Timing Control
> CPU Power Management
2.4.1

Memory Frequency [Auto]

Allows you to set the memory operating frequency. Configuration options: [Auto]
[DDR3-800MHz] [DDR3-1066MHz] [DDR3-1333MHz]
Selecting a very high memory frequency may cause the system to become unstable! If this
happens, revert to the default setting.
2.4.2

iGPU Max. Frequency [Auto]

Allows you to set the maximum frequency for the internal GPU. Use the <+> and <-> keys to
adjust the value. You can also key in the desired value using the numeric keypad. The values
range from 1100MHz to 3000MHz.
2.4.3

GPU Boost

GPU Boost accelerates the integrated GPU for extreme graphics performance.
Configuration options: [OK] [Cancel]
2-12
Ai Tweaker
Advanced
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Monitor
Forces a DDR3 frequency slower than
the common tCKdetected via SPD.
Auto
According to Intel spec, ASUS H61 Series
motherboard supports 1066/1333MHz
Auto
DRAM (only).
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save
F12: Print Screen
Exit
Boot Tool
ESC: Exit
ASUS P8H61-M2 Series
