Intel Desktop Board D945PLNM Product Guide

Installing and Removing the Desktop Board

CAUTION
Only qualified technical personnel should do this procedure. Disconnect the computer from its
power source before performing the procedures described here. Failure to disconnect the power
before you open the computer can result in personal injury or equipment damage.
Refer to your chassis manual for instructions on installing and removing the desktop board.
Figure 5 shows the location of the eight mounting screw holes for Desktop Board D945PLNM.
Figure 5. Desktop Board D945PLNM Mounting Screw Hole Locations
26
OM19076
