Lexmark CS510 Moving Manual

Moving guide

Before moving the printer

CAUTION—POTENTIAL INJURY: The printer weight is greater than 18 kg (40 lb) and requires two or more trained
personnel to lift it safely.
CAUTION—POTENTIAL INJURY: Before moving the printer, follow these guidelines to avoid personal injury or printer
damage:
•
Turn the printer off using the power switch, and then unplug the power cord from the electrical outlet.
• Disconnect all cords and cables from the printer before moving it.
•
Lift the printer off the optional tray, and then set it aside instead of trying to lift the tray and printer at the same time.
Note: Use the handholds located on both sides of the printer to lift it.
Warning—Potential Damage: Damage to the printer caused by improper moving is not covered by the printer warranty.

Selecting a location for the printer

When selecting a location for the printer, leave enough room to open trays, covers, and doors. If you plan to install any hardware
options, then leave enough room for them also. It is important to:
•
Set up the printer near a properly grounded and easily accessible electrical outlet.
• Make sure airflow in the room meets the latest revision of the ASHRAE 62 standard or the CEN Technical Committee 156
standard.
• Provide a flat, sturdy, and stable surface.
•
Keep the printer:
– Clean, dry, and free of dust.
–
Away from stray staples and paper clips.
– Away from the direct airflow of air conditioners, heaters, or ventilators.
–
Free from direct sunlight and humidity extremes.
• Observe the recommended temperatures and avoid fluctuations.
Ambient temperature 15.6 to 32.2°C (60 to 90°F)
Storage temperature -40 to 43°C (-40 to 110°F)
•
Allow the following recommended amount of space around the printer for proper ventilation:
Moving guide
Page 1 of 2
