- Page 1 MODEL XJ-600R DIGITAL FEEDBACK CLASS “J” MONOBLOCK AMPLIFIER USERS MANUAL www.earthquakesound.com Sound That Will Move You...
- Page 2 EQ the room. For that reason extreme operating conditions. Earthquake’s XJ-600R is truly an intelligent system. 20Hz, 30Hz and 40Hz frequencies can be cut or boosted by a whopping 12dB, these corrections help in producing wider range of listening position that is unprecedented for the The XJ-600R is a ruggedly constructed high quality professional amplifier.
-
Page 3: Unpacking And Warnings
Subwoofer Power Amplifier Unpacking and Warnings XJ-600R ITEMIZED LIST OF INCLUDED ACCESSORIES: 1. One (1) AC Power Cable 2. One (1) Users Manual 3. One (1) Registration/Warranty Card 4. One (1) Remote Control 4. Rack Mounting Brackets and Screws When you have safely removed the amplifier from the packaging and placed it in a safe area, perform a thorough physical inspection and report any damage to the dealer that you purchased the unit from. -
Page 4: Subwoofer Placement Guide
Fully complementary sub-harmonics to the mids dimensional front-end bass that allows you to have a low and the highs frequency dynamic stage, Earthquake designed dual input circuits that use buffers to maintain your stereo separation on the processor side while mixing stereo front signals to produce 3D bass. -
Page 5: Front And Back Panel Overview
Subwoofer Power Amplifier Front and Back Panel Overview XJ-600R 24dB/Oct Lowpass Main Power 0-180° Phase Room Equalization Channel and Power Crossover With ON/OFF Switch Correction Adjustment Center Status LEDs Bypass Option POWER SUBSONIC PHASE SHIFT PHASE DELAY ROOM CORRECTION GAIN CROSSOVER POWER 20Hz... - Page 6 Subwoofer Power Amplifier Single Subwoofer (Stereo & Mono) Connection XJ-600R The back side of a typical processor or receiver GOOD Single subwoofer application RCA splitters can be used to double the input signal strength. Maximum output can be reached with 400mv input, using one RCA.
- Page 7 Subwoofer Power Amplifier Dual Subwoofer (Stereo & Mono) Connection XJ-600R The back side of a typical processor or receiver BEST Three dimensional subharmonic system using two XJ600-R and two subwoofers HI-LEVEL HI-LEVEL SPEAKER OUTPUT 110-120V 220-240V 6.3 AMPS 110-120V~/60Hz 110-120V, FUS E T6.3AL/250V INPU INPU TRIGGER...
-
Page 8: Room Correction
Once that is achieved the user will resort to the final correction- EQ the room. For that reason Earthquake’s XJ-600R is truly an intelligent system. 20Hz, 30Hz and 40Hz frequencies can be cut or boosted by a whopping 12dB, these corrections help in producing wider range of listening position that is unprecedented for the room. -
Page 9: Amplifier Specifications
Amplifier Specifications Subwoofer Power Amplifier XJ-600R POWER OUTPUT 1 x 700 watts RMS @ 2-Ohms 1 x 570 watts RMS @ 4-Ohms 1 x 320 watts RMS @ 8-Ohms FREQUENCY RESPONSE 10Hz - 2.4kHz TOTAL HARMONIC DISTORTION <0.08%, (1W/4ohm) SLEW RATE 50 volts / microsecond SIGNAL TO NOISE RATIO >... -
Page 10: Troubleshooting Information
LED status to turn GREEN. If you have tried and failed with all of the provided solution then you should call Earthquake for further assistance: 800-576-7944 Specifications Are Subject To Change Without Notice... - Page 11 (F) Shipping Instructions: (C) Earthquake agrees to repair or replace - at our option - all such defective Product/s must be packaged in its original protective box/s to minimize products/parts subject to the following provisions: transport damage.
- Page 12 Sound That Will Move You Earthquake Sound reserves the right to amend details of the specifications without notice. Copyright© Earthquake Sound Corporation Earthquake Sound Corporation • 2727 McCone Avenue Hayward CA, 94545 Phone: 510-732-1000 Fax: 510-732-1095...
