Lightolier Lytecaster 377X Specification

Page 1 of 2
4 1/2"

Ceiling Cutout:

Complete fixture consists of Reflector Trim & Frame-in Kit. Select each separately

Reflector Trim

377WHX Frosted glass and white flange
377CHX
Frosted glass and chrome flange

Features

1. Housing: 25ga. galvanized steel
2. Residence Mounting Clip: Factory-installed; zinc plated spring steel free-
hand installation.
3. Flange: Die-cast aluminum .060" (1.5mm) thick.
4. Glass: Frosted glass.
5. Gasket: Seal unit for shower applications.
6. Lampholder Support: 27ga. steel.
7. Mounting Clips (3): 24ga. spring steel, zinc plated. Provides easy snap-in
snap-out action.

Frame-In Kit

Note: For complete Frame-In Kit specifications, see 300 frame
specification sheets
Labels:
CSA , UL (Suitable for damp and wet locations.)
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2012 Philips Group • D0212
Lytecaster
1/4"
4 1/2"
Frame-In-Kit
Remodeler
Remodeler
Non-IC
Non-IC
IC
Air Seal / IC 302MRAICSPX
Air Seal / IC 302MRAICEX
Recessed Downlight
®
3 3/4" (95mm) Aperture Shower Light (Flat Lens) MR16
1" MAX
300MRSPX
3401MREX
302MRSPX
302MREX
302MRIC9SPX
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
377X
Lamp
50W MR16
50W MR16
50W MR16
50W MR16
50W MR16
50W MR16
50W MR16
Type:
