Lytecaster Recessed Downlighting
3-3/4" Aperture Thick Ceiling Kit
Complete fixture consists of the Housing, Trim and Frame-in Kit. Select each separately.
Trim
Housing
300XTC
300X Series
Features
Housing: 24ga galvanized steel.
Thick Ceiling Clip: Factory-installed; zinc plated spring steel with locking
feature for easy installation into ceiling.
Adaptor Plate (Supplied): To be used only with remodeler kits.
(Note: Not required for IC and IC AIRSEAL Frame-in kits).
Frame-In-Kit
Note: For complete Frame-In Kit specifications, see No.300X frame
specification sheets.
Trim
Note: For complete Trim specifications, see No.300X trim
specification sheets.
Markings
cCSAus Certified, suitable for damp or wet locations depending on trim used.
We reserve the right to change details of design, materials and finish.
Frame-in kit
300MRX
NON-IC
300ESX
NON-IC
3401MREX
NON-IC
302MRIC7X
IC
302MRIC9X
IC
302ESICX
IC
302MRAICX
IC AIRSEAL
302MRAICEX
IC AIRSEAL
302ESAICX
IC AIRSEAL
300XTC
Rev 02-2006
Ceiling Opening: 3-3/4" (95mm)
Adaptor Plate for
Remodeler Kits
