Lightolier ProSpec 37121 Specification

ProSpec
9 9/32"
[235 mm]
5 1/2"
[140 mm]
Catalog No. Finish
37121WH White
37121BK Black
Features
1. Track Attachment Fitting: Molded polycarbonate,
rotates into track.
2. Locking Lever: Steel pin locks and detaches unit.
3. Track Adaptor Housing: Die-cast aluminum.
4. Ballast Housing: Extruded aluminum housing with
die-cast aluminum covers.
5. Ballast: Electronic HID.
6. Pivot Mounts: Allows for 350° horizontal and 180°
vertical rotation with tensioned mounts for controlled aim.
7. Housing: 0.04" (1.02mm) aluminum.
8. Lampholder: Bi-pin G12 single-ended base. 5kV pulse
rated porcelain body socket with nickel-plated contacts. 18
AWG silicone leads with fiberglass outer sleeve hidden
inside of housing.
9. Protective Glass: 0.13" (3.18mm) tempered glass.
10. Housing Cover: 0.04" (1.02mm) aluminum.
11. Knobs: Steel painted knurled knob.
277V HID, Cylinder, 39W T6 CMH
™
1
3
5"
[127 mm]
8
6
7
11
9
10
Mounting
ProSpec 120V/277V
®
track systems only.
2
n5"
4
[127 mm]
5
7 7/32"
[184 mm] 8 5/8"
[219 mm]
5 9/32"
[134 mm]
Lamp Reflectors (Sold Separately)
39W T6 CMH Spot Reflector: MHT6RS, MHT6RSCCZ
G12 base Narrow Flood Reflector: MHT6RNF,
Not included MHT6RNFCCZ
Flood Reflector: MHT6RF, MHT6RFCCZ
Accessories (Holds one accessory only)
Diffusion/ Special Filters: AF4 series
Color Filters: ADF4 series
Louver (Hex Cell): AL4HC
Electrical
Electronic Ballast (Thermally Protected)
Input Voltage: 120V/277V
Power Factor: >0.99
Input Power: 44W
Max Input Current: 0.37A@120V/0.16A@277V
Finish
All painted finishes are baked powder or enamel.
Markings
UL, cUL
Job Information
Job Name:
Cat. No.:
Notes:
37121
[63 mm]
1 5/8"
[41 mm]
Total Harmonic Distortion: <10%
ANSI Code: M 130
Do not use on dimming circuit
Type:
Page 1 of 3
2 1/2"
