Hunter 20807 Parts Manual

P P AR
P P AR
Using the Parts Guide below, check to make sure all parts are included in the box.
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE.
Before installing your fan, record the following information for your records and warranty assistance.
46 Blade Set
44 Blade Iron Set
64 Wood Screw
69 Screw, Machine, 6-32
47 Screw, Blade Iron
Armature
67
ARTS GUIDE TS GUIDE
ARTS GUIDE TS GUIDE
If parts are missing or damaged call 1-888-830-1326.

Fan Parts

Motor / Housing Assembly
Switch /
28 Housing
Assembly
Hardware
65 Wood Screw
68 Flat Washer
Screw, Blade Assembly
(Not Drawn to Scale)
239 Hanger Bracket Assembly
226
Motor Cover
(Drawn to Scale)
70 Wire Nut
66 Blade Grommet
Model Name
Catalog No.
Serial No.
Date Purchased
Where Purchased
Missing / Broken Parts:
Call 1-888-830-1326
Fan does not work:
1. Reference the Trouble Shooting guide in
your Instruction Manual.
2. Call your Local Service Center.
3. Call Technical Support at 901-248-2222.
For additional information on:
Hunter Products
Dealer Location
Call 1-800-448-6837
www.hunterfan.com
75 Balancing Kit
71
Mounting
Isolator
Trouble Shooting
Service Center Locator
R
