Lightolier Lensed 1050SQIN Specification

Page 1 of 2
2.27"
(58 mm)
Complete Fixture consists of Frame-In Kit and Reflector Trim. Select each separately.
Xceed Compact Fluorescent Lensed Square Reflector
Trims
Catalog No. Description
1050SQINFBW 5" Lensed Square Indirect Flush - White
†All frames come standard with preset mounting screws and a 2700K lamp. Models are available with preset nails and/or a 3500K lamp (13ES/13CMU = 2700K only).
*Simply add an "N" and/or 35 to the end of the model number for those options. **Simply add an N and/or 35 before the "U" in the model number for those options.
Features
1. Upper Reflector: Formed aluminum. Highly reflective corrosion resistant
anodized finish.
2. Lower Baffle / Cone: Injection molded non-yellowing Polycarbonate plastic
trim. Matte white finish.
3. Lens: 1/8" thick high transmission soda lime glass. Solite texture to hide
visibility to the lamp.
4. Finish: W= Matte white
5. Performance Data: See attached photometric reports for distribution
and efficiency data. Go to www.lightolier.com for .IES files.
Labels
cULus Listed. Suitable for damp Locations. I.B.E.W.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • A0809
Lensed Recessed CFL Downlighting
4
4.47"
(114 mm)
2.27"
(58 mm)
6.00"
(152 mm)
Front View
of Trim
3
2
Wall
Min 3/8" (10 mm)
Max 1 1/2" (38 mm)
5" Square Lensed, CFL, Indirect Reflector Trim
3.74"
(95 mm)
1
3.47"
(88 mm)
Frame
Height
Compatible Xceed Frame-In Kits
(See Individual Frame-In Kit Specification Sheets)
Catalog No. Installation Type
1050SQ13ES †* IC Airseal
1050SQ18ES †*
IC Airseal
1050SQ26ES †* IC Airseal
1050DSQ26ES †* IC Airseal
1050SQ13CMU †** Non-IC Airseal
1050SQ18CMU †** Non-IC Airseal
1050SQ26CMU †** Non-IC Airseal
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
1050SQIN
Lamping
120v 13w Triple
®
120v 18w Triple
®
120v 26w Triple
®
Energy Star Dimming 120V 26w Triple
® ®
120/277v 13w Triple
®
120/277v 18w Triple
®
120/277v 26W Triple
®
Type:
