Lightolier Lytecaster 1090 Specification

Page 1 of 1
1
5 1/4"
1/4
2
1090/1002P1 Series
Standard Incandescent
1090/1004IC
0
Non-IC only
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit
1090
1001LED
1001LEDEM
1000LEDREM
Frame-In Kit
1002P1
1003R
1000IC
1000AICM
1004ICX/N
1004IC/N
1004ICR
Features
1. Housing: Hydroformed aluminum, .040 thick. min. Non-yellowing, gloss
white powder coat finish for permanent reflectivity and surface protection.
2. Trim Flange: Frosted clear polycarbonate flange ring. Pull down and release
for toolless relamping.
3. Frame-In Kit: (1002PI standard frame shown) Other frames noted. See
Frame-In Kit specification sheets for more details.
4. Glass: Pressed borosilicate glass textured diffuser. Smooth surface on
exposed side for wipe down cleaning. Meets NEC
hot tubs. May be installed less than 7' 6" above max water surface height.
Labels
UL (Suitable for Wet Locations - Covered Ceilings only), I.B.E.W.
NEC ® is a registered trademark of the National Fire Protection Association.
3
4 1/8"
4
5 7/8"
7 1/2"
Convertible
™
Installation Type Lamping
Non-IC LED
Non-IC EM LED
Non-IC Remodeler LED
Non-IC Retrofit LED
Ceiling Type Lamping
Non-IC 75W PAR30L
Non-IC Remodeler
IC 60W PAR30S
AirSeal IC
®
AirSeal IC
®
Non-IC 75W PAR30S
Non-IC Remodeler
requirements for spas and
®
Lytecaster Recessed Downlighting
®
5" Aperture Flush Glass Wet Location Trim
1 1/4" MAX.
5 1/4"
1090/1003R
0
Non-IC
™
Remodeler Ring
LED
Height
5 1/4"
5 1/4"
5 1/4"
5 1/4"
Incandescent
Height
5 1/4"
5 1/4"
7 5/16"
7 5/16"
7 1/4"
7 1/2"
7 1/2"
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • G0711
1090/1004ICX
0
AirSeal Insulated Ceiling
™ ®
Type:
www.lightolier.com
1090
7 5/8"
