Lightolier Uniframe Lytecaster 2001SW Specification

Lytecaster
Page 1 of 2
7 1/4"
Complete Fixture consists of Frame-In Kit and Reflector Trim. Select each separately.
Uniframe™ Compact Fluorescent Performance
Series Reflector Trims
Catalog No. Description
2001CLSW 3-3/4" Vertical Single Wall Wash – Specular Clear
2001CDSW 3-3/4" Vertical Single Wall Wash – Clear Diffuse
2001WHSW
3-3/4" Vertical Single Wall Wash – Matte White
Features
1. Reflector: Formed aluminum. Matte White flange.
2. Finishes: CL = Specular Clear (Iridescent Free coating)
CD = Clear Diffuse
WH = Matte White Paint
3. Wall Wash Kick Reflector: Formed aluminum. Clear finish.
4. Performance Data: 65° Cutoff angle.
See attached photometric reports for distribution and efficiency data.
Go to www.lightolier.com for .IES files.
Performance Recessed CFL Downlighting
®
3 ¾" Aperture Vertical Wall Wash, Compact Fluorescent, Performance Series,
Compatible Frame-In Kits
(See Individual Frame-In Kit Specification Sheets)
Catalog No.
2001F13U
2001F18U
2001F13ICU/N
2001F18ICU/N
3 5/8"
4 1/2"
Installation Type
Uniframe Non-IC 120/277v
™
Uniframe Non-IC 120/277v
™
Performance IC 120/277
Performance IC 120/277
Labels
cULus Listed. Suitable for Damp Locations. I.B.E.W.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2007 Genlyte Group LLC • D1007
2001SW
Reflector Trim
Lamping
13w Quad/Triple
18w Triple
13w Quad/Triple
18w Triple
Type:
www.lightolier.com
