- Page 1 Model 6002, 6003, 6004 Unidirectional Widely Spaced Wavelength Division Multiplexer (WWDM) Users Manual...
- Page 2 ® EdgeAccess Universal Chassis System Caution! This product is a passive device that may route light emitted by a laser diode operating at a wavelength of 1300nm - 1600nm. Use of optical instruments (for example: collimating optics) with this product may increase eye hazard. Use of controls or adjustments or performing procedures other than those specified herein may result in hazardous radiation exposure.
- Page 3 ® EdgeAccess Universal Chassis System NOTICE Canoga Perkins has prepared this user manual for use by customers and Canoga Perkins personnel as a guide for the proper installation, operation and/or maintenance of Canoga Perkins equipment. The drawings, specifications and information contained in this document are the property of Canoga Perkins and any unauthorized use or disclosure of such drawings, specifications and information is prohibited.
- Page 4 ® EdgeAccess Universal Chassis System Canoga Perkins ® EdgeAccess Universal Chassis System (UCS) Model 6002, 6003, 6004 (6002/3/4) Unidirectional Widely Spaced Wavelength Division Multiplexer (WWDM) 6002/6003/6004 WWDM Users Manual...
-
Page 5: Table Of Contents
® EdgeAccess Universal Chassis System Table of Contents Chapter 1 General Overview ................. 1-1 Overview....................1-1 Stand Alone 6002/3/4 Models.............. 1-2 Rack Mount 6002/3/4 Models .............. 1-2 Chapter 2 Set-up and Installation ..............2-1 Unpacking and Installing the Stand Alone Models....... 2-1 Unpacking and Installing the Rack Mount Models ....... - Page 6 ® EdgeAccess Universal Chassis System Appendix A Warranty Warranty ....................A-1 A.1.1 Electronic Products................A-1 A.1.2 Cable Products ..................A-1 A.1.3 Limitations.................... A-2 Customer Service Department Repair Warranty........A-2 Return Policy ..................A-2 Extended Warranty Policy..............A-3 List of Figures Figure 1.
-
Page 7: Chapter 1 General Overview
® EdgeAccess Universal Chassis System Chapter 1 General Overview Overview EdgeAccess Models 6002, 6003, 6004 (6002/3/4) ® are passive, unidirectional Widely spaced Wavelength Division Multiplexers (WWDM) that fit into the EdgeAccess Universal Chassis System (UCS), or a stand alone enclosure. The WWDM multiplexes (MUX) two to four optical signals onto a single composite signal for transmission to a remote location. -
Page 8: Stand Alone 6002/3/4 Models
® EdgeAccess Universal Chassis System Stand Alone 6002/3/4 Models The 6002/3/4 stand alone models are passive, non-powered devices. The models have no user configurable switches and require no management aware connections. Because these models have no electrical components, they can fit easily into multiple environments. The stand alone Model 6000 Optical Multiplexer shown in Figure 2, represents the 6002/3/4 stand alone (SA) series. -
Page 9: Chapter 2 Set-Up And Installation
® EdgeAccess Universal Chassis System Chapter 2 Set-up and Installation Unpacking and Installing the Stand Alone Models Each stand alone 6002/3/4 is factory tested and shipped in protective cartons. After unpacking the unit and its accessories, retain the shipping carton and protective packing material in the event a need arises in which the equipment must be returned to the factory. -
Page 10: Cabling
® EdgeAccess Universal Chassis System Cabling The 6002/3/4 models are passive, unidirectional wavelength division multiplexers. Each module allows simultaneous transmission of two to four optical signals over a single fiber pair. 2.4.1 Fiber Optic Cabling Optical cabled devices transmit (Tx) and receive (Rx) channel-to-channel signals through local and remote modules. -
Page 11: Checking Optical Power Levels
® EdgeAccess Universal Chassis System 2.4.4 Checking Optical Power Levels Each 6002/3/4 model is shipped with a document that lists the specific output power for each local and remote laser. To ensure proper optical performance levels, the link loss or attenuation of all fiber cables should be measured and identified. -
Page 12: Measuring Receiver Input Power
® EdgeAccess Universal Chassis System 2.4.6 Measuring Receiver Input Power If the link attenuation is not known, the Model 6002/3/4 can be used to measure the link loss or attenuation. If the link attenuation is already known – skip this section. To measure the link attenuation: Step 1 At the local site, connect the remote fiber link cable to the remote Tx connector on the 6002/3/4 model. -
Page 13: Chapter 3 User Operation
® EdgeAccess Universal Chassis System Chapter 3 User Operation WWDM Application WWDM (widely spaced wavelength division multiplexer) models multiplex and demultiplex wavelengths in the 1310nm, 1480nm, and 1550nm windows, and are protocol, speed, and line code transparent. Each 6002/3/4 model is unidirectional (meaning that light travels in only one direction on a fiber line) and transmits signals through a composite pair of single mode fibers. -
Page 14: Operation Of The Stand Alone Models
® EdgeAccess Universal Chassis System Operation of the Stand Alone Models To ensure proper optical performance levels, you will need to determine the loss budget. This factor will ensure link integrity and ample signal strength at the remote end of your link. To operate the 6002 stand alone model: Step 1 Measure each of the optical composite fiber links at the lowest wavelength of operation. -
Page 15: Operation Of The Rack Mount Models
® EdgeAccess Universal Chassis System Operation of the Rack Mount Models When the 6002/3/4 RM module is installed into the EdgeAccess Universal Chassis System, a “STA” or status LED on the front panel will illuminate amber. This test signal from the UCS verifies that a backplane connection was established. - Page 16 ® EdgeAccess Universal Chassis System This Page is Intentionally Left Blank 6002/6003/6004 WWDM Users Manual...
-
Page 17: Chapter 4 Software Interaction
® EdgeAccess Universal Chassis System Chapter 4 Software Interaction Universal Chassis System Software When the rack mount 6002/3/4 models are properly installed in a managed UCS 1000 Chassis, the DMM module will open the required HyperTerminal™ software. The computer application will display the screenshots shown in this section. -
Page 18: Figure 9. Chassis Management Screen Showing Inserted Modules
® EdgeAccess Universal Chassis System The DMM will show that two Model 6002-LightWave Modules are inserted into Chassis 1 on the LOCAL UCS. The Status of Slots 4 & 5 will show OK. Figure 9. Chassis Management Screen Showing Inserted Modules To access inserted modules from the UCS DMM Chassis Management screen: •... -
Page 19: Naming The Wdm Module In A Chassis Configuration
® EdgeAccess Universal Chassis System Naming the WDM module in a Chassis Configuration In many applications, it may be beneficial to name the WDM module in the UCS Chassis or the circuit path that it is part of. This identification feature is useful to name the circuit designations of all connected modules. -
Page 20: Figure 12. Entering A Descriptive Name For The 6002 Module
® EdgeAccess Universal Chassis System Naming the Chassis / Slot number of the installed module: • The Module Menu screen will appear, note the example in Figure 12 shows that the 6002- LightWave module is inserted into Chassis 1, Slot 4. •... -
Page 21: Chapter 5 Troubleshooting And Maintenance
® EdgeAccess Universal Chassis System Chapter 5 Troubleshooting and Maintenance Troubleshooting Fiber Optic Cables All optical cables should be connected using a Tx to Rx, or Rx to Tx orientation for correct MUX and DEMUX signal operation. Proper labeling of each connecting cable is highly recommended. Troubleshooting Guide The 6002/3/4 models are passive, unidirectional WWDMs. -
Page 22: Maintenance
® EdgeAccess Universal Chassis System Maintenance The Model 6002/3/4 is designed to perform at specified performance levels. Damaged fiber cables and dirty connectors are a common source of signal loss or link attenuation. Single mode optical fibers should be checked frequently. Inspect and test all suspect components to maintain optimal system performance levels. -
Page 23: Chapter 6 Specifications
® EdgeAccess Universal Chassis System Chapter 6 Specifications Single Mode Specifications 6.1.1 Local Channels Data Rate: Speed transparent Protocols: All, no limitation Fiber: Single mode (SMF) Optical Connector: ST, FC/PC, or SC Duplex APC connectors (special order) 6.1.2 Remote Channels Composite Data Rate: Speed transparent Protocols: All, no limitation... -
Page 24: Wwdm Model Specifications
® EdgeAccess Universal Chassis System WWDM Model Specifications The Model 6002/3/4 is available in a variety of user-specified wavelengths and loss budget configurations. All end-to-end loss calculations were figured at maximum loss values. Note: Actual attenuation loss values should be used when computing final loss budgets. Basic channel features and wavelengths are defined in Tables 2 through 4. -
Page 25: Unidirectional Three Channel Wwdm
® EdgeAccess Universal Chassis System 6.2.2 Unidirectional Three Channel WWDM The Model 6003 is a three channel unidirectional module with various wavelength configurations. Table 3 shows current available model options. Table 3. Unidirectional Three Channel WWDM Chart MODEL MODEL WAVELENGTH END-TO-END DIRECTIVITY ISOLATION... - Page 26 ® EdgeAccess Universal Chassis System This Page is Intentionally Left Blank 6002/6003/6004 WWDM Users Manual...
-
Page 27: Appendix A Warranty Warranty
® EdgeAccess Universal Chassis System Appendix A Warranty Warranty A.1.1 Electronic Products Canoga Perkins warrants to the Customer that all goods sold to the Buyer will perform in accordance with the applicable data sheets, drawings or written specifications, and at the time of sale will be free of defects in material and workmanship. -
Page 28: Limitations
® EdgeAccess Universal Chassis System A.1.3 Limitations Other than those expressly stated herein, THERE ARE NO OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AND SPECIFICALLY EXCLUDED BUT NOT BY WAY OF LIMITATION, ARE THE IMPLIED WARRANTIES FOR FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY. -
Page 29: Extended Warranty Policy
® EdgeAccess Universal Chassis System Extended Warranty Policy Canoga Perkins will, at its factory location, repair all defects occurring in Canoga Perkins products for a period of one year after the expiration of the original three-year factory warranty for a fee equal to six (6) percent of the current list price of the product. The product must be placed under extended warranty by written order from the customer and may be renewed for up to three years beyond the original extension.
