Panasonic DMC-GF3XK Brochure

Specifications
Type Digital interchangeable lens system camera
Recording Media SD Memory Card, SDHC Memory Card, SDXC Memory Card
TYPE
Image Sensor Size 17.3 x 13.0 mm (in 4:3 aspect ratio)
Lens Mount Micro Four Thirds mount
Type Live MOS Sensor
Total Pixels 13.06 Megapixels
Camera Effective Pixels 12.10 Megapixels
SENSOR
Color Filter Primary color filter
Dust Reduction System Supersonic wave filter
Still Image: JPEG (DCF, Exif 2.3), RAW
Recording File Format MPO (When attaching 3D lens in Micro Four Thirds System standard)
Motion Image: AVCHD / QuickTime Motion JPEG
Aspect Ratio 4:3, 3:2, 16:9, 1:1
RAW, RAW+Fine, RAW+Standard, Fine, Standard,
Image Quality
MPO+Fine, MPO+Standard (When attaching 3D lens in Micro Four Thirds System standard)
Color Space sRGB, Adobe RGB
[4:3] 4,000 x 3,000 (L) / 2,816 x 2,112 (M) / 2,048 x 1,536 (S) /
1,600 x 1,200 (When attaching 3D lens in Micro Four Thirds System standard)
[3:2] 4,000 x 2,672 (L) / 2,816 x 1,880 (M) / 2,048 x 1,360 (S) /
1,600 x 1,064 (When attaching 3D lens in Micro Four Thirds System standard)
Still Image
[16:9] 4,000 x 2,248 (L) / 2,816 x 1,584 (M) / 1,920 x 1,080 (S) /
1,600 x 904 (When attaching 3D lens in Micro Four Thirds System standard)
RECORDING
SYSTEM
[1:1] 2,992 x 2,992 (L) / 2,112 x 2,112 (M) / 1,504 x 1,504 (S) /
File
1,440 x 1,440 (When attaching 3D lens in Micro Four Thirds System standard)
Size
(Pixels)
[4:3] VGA : 640 x 480, 30fps / QVGA : 320 x 240, 30fps
Motion JPEG
[HD] 1,280 x 720, 30fps
Motion [Full HD] 1,920 x 1,080, 60i (sensor output is 30p) (FSH: 17Mbps)
NTSC
[HD] 1,280 x 720, 60p (sensor output is 30p) (SH: 17Mbps)
AVCHD
[Full HD] 1,920×1,080, 50i (sensor output is 25p) (FSH:17Mbps)
PAL
[HD] 1,280 x 720, 50p (sensor output is 25p) (SH:17Mbps)
Continuous Recordable Time AVCHD with picture quality set to [FSH]:
(Motion images) Approx. 130 min with H-FS014042 / Approx. 150 min with H-H014
Actual Recordable Time AVCHD with picture quality set to [FSH]:
(Motion images) Approx. 65 min with H-FS014042 / Approx. 75 min with H-H014
Type Contrast AF system
Focus Mode AFS / AFC / MF
AF Mode Face detection / AF Tracking / 23-area-focusing / 1-area-focusing / Pinpoint
AF Detective Range EV 0 - 18 (ISO100 equivalent)
FOCUS
AF Assist Lamp YES
AF Lock Set the Fn button in custom menu to AF/AE lock
Touch shutter, Quick AF, Continuous AF (during motion image recording),
Others
AF+MF, Touch MF Assist
Light Metering System 144-zone multi-pattern sensing system
Light Metering Mode Intelligent Multiple / Center Weighted / Spot
Metering Range EV 0 - 18 (F2.0 lens, ISO100 equivalent)
Exposure Mode Program AE / Aperture Priority AE / Shutter Priority AE / Manual
EXPOSURE
ISO Sensitivity
CONTROL Auto / Intelligent ISO / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400
(Standard Output Sensitivity)
Exposure Compensation 1/3 EV Step ±3 EV
AE Lock Set the Fn button in custom menu to AF/AE lock
AE Bracket 3, 5 frames, in 1/3 or 2/3 EV Step, ±4/3 EV
Auto / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2 / Color temperature
White Balance
setting / Portrait / Beauty Skin / Sports / Flower / Collection / Baby / Pet / Defocus Control
WHITE
White Balance Adjustment Blue/amber bias, Magenta/green bias
BALANCE
Color Temperature Setting 2,500K - 10,000K in 100K
White Balance Bracket 3 exposures in blue/amber axis or in magenta/green axis
Type Focal-plane shutter
Still Images: 1/4,000 - 60
SHUTTER Shutter Speed
Motion Image: 1/16,000 - 1/30 (NTSC), 1/16,000 - 1/25 (PAL)
Self Timer 10 sec, 3 images / 2 sec / 10 sec
Portrait / Soft Skin / Scenery / Architecture / Sports / Peripheral Defocus / Flower / Food /
Still Image SCN Mode
Objects / Night Portrait / Night Scenery / Illuminations / Baby 1, 2 / Pet / Party / Sunset
Portrait / Soft Skin / Scenery / Architecture / Sports / Flower / Food /
SCENE MODE
Objects / Low-light / Party / Sunset
Video SCN Mode (Activated by selecting Still Image SCN mode then pressing Video Button.
Still Image SCN modes without corresponding Video SCN mode is recorded
in mode suitable for the recording situation.)
CREATIVE
Creative Control (Still Image & Motion Image) Expressive / Retro / High Key / Sepia / High Dynamic / Miniature
CONTROL
Burst Speed H: 3.8 frames/sec, M: 2.8 frames/sec (with Live View), L: 2 frames/sec (with Live View)
BURST
7 images (when there are RAW files with the particular speed)
SHOOTING
Number of Recordable Images Unlimited consecutive shooting (when there are no RAW files)
(depending on memory card size, battery power, picture size, and compression)
Type TTL Built-in-Flash, GN6.3 equivalent (ISO160 · m), Built-in Pop-up
Auto, Auto / Red-eye Reduction, Forced On, Forced On / Red-eye Reduction,
Flash Mode
BUILT-IN-
Slow Sync., Slow Sync. / Red-eye Reduction, Forced Off
FLASH
Synchronization Speed Less than 1/160 second
Flash Synchronization 1st Curtain Sync.
Type TFT LCD with Touch panel
Monitor Size 3.0 inch / 3:2 Aspect / Wide-viewing angle
LCD MONITOR Pixels 460,000 dots
Field of View Approx. 100%
Monitor Adjustment Brightness (7 levels), Contrast and Saturation (7 levels), Red tint (7 levels), Blue tint (7 levels)
Digital Zoom 2x, 4x
Still image: Max. 2x (Not effective with L size recording.
Magnification ratio depends on the recording pixels and aspect ratio.)
Extra Tele Conversion
Motion image: 3.1x (SH in AVCHD and HD in Motion JPEG),
LIVE VIEW
4.2x (VGA/QVGA in Motion JPEG)
Guide Lines (3 patterns)
Other Functions
Real-time Histogram
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display,
Zoomed playback (Max. 16x), Slideshow (duration & effect is selectable),
PLAYBACK Playback Mode Playback Mode (Normal / Picture / AVCHD / Motion JPEG / 3D Play / Category / Favorite),
Title Edit, Text Stamp, Video Divide, Resize, Cropping, Aspect Conversion, Rotate,
Rotate Display, Favorite, Print Set, Protect, Face Recognition Edit
IMAGE Protection Single / Multi, Single in Burst Group / Multi in Burst Group, Cancel
PROTECTION /
Erase Single / Multi / All / Except Favorite
ERASE
PRINT Direct print PictBridge compatible (Print size, Layout, and Date setting are selectable)
USB USB 2.0 High Speed
mini HDMI TypeC
HDMI Video: Auto / 1080i / 720p / 480p (576p in PAL system)
Audio: Linear PCM
Monaural Type, NTSC / PAL, NTSC only for North America
INTERFACE
Audio Video Output *Check the website of the Panasonic sales company in your country or region
for details on the products that are available in your market.
Monaural, Wind-cut: Off / Low / Standard / High
Microphone
Microphone level adjustable: Lv1 / Lv2 / Lv3 / Lv4
Speaker Monaural
English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Russian,
Chinese (Traditional), Chinese (Simplified), Dutch, Thai, Korean, Turkish, Portuguese,
LANGUAGE OSD Language Arabic, Persian, Japanese, Swedish, Danish, Finnish, Greek, Vietnamese
*Check the website of the Panasonic sales company in your country or region for details on the
OSD languages on the products that are available in your market.
Li-ion Battery Pack (7.2V, 940mAh) (Included)
Battery
Battery Charger
POWER
Approx. 320 images with H-FS014042
Battery Life (CIPA Standard)*
Approx. 340 images with H-H014
Dimensions (W x H x D) 107.7 x 67.1 x 32.5 mm / 4.24 x 2.64 x 1.28 inch (excluding protrusions)
Approx. 264 g / 9.31 oz (SD card, Battery, Body)
DIMENSIONS /
Approx. 222 g / 7.83 oz (Body only)
WEIGHT
Weight
Approx. 319 g / 11.25 oz (SD card, Battery, H-H014 lens included)
Approx. 429 g / 15.13 oz (SD card, Battery, H-FS014042 lens included)
Operating Temperature 0ºC to 40ºC (32°F to 104°F)
OPERATING
ENVIRONMENT
Operating Humidity 10%RH to 80%RH
PHOTOfunSTUDIO 6.2 HD Edition,
SILKYPIX® Developer Studio 3.1 SE,
Software
Super LoiLoScope (trial version),
USB Driver
STANDARD
ACCESSORIES
Battery Charger, Body Cap (DMC-GF3K and DMC-GF3 only), AV Cable,
USB Connection Cable, Shoulder Strap, Stylus Pen, CD-ROM
Standard Accessories
*Body cap not included for the DMC-GF3C kit and the DMC-GF3W kit
**Lens rear cap of H-H014 lens not included for the DMC-GF3C kit and the DMC-GF3W kit
* Shooting conditions: 23ºC with 50%RH humidity; LCD on; Using a Panasonic SD Memory Card (2GB); Using the supplied battery;
Using the supplied lens; Starting recording 30 seconds after the camera is turned on (When the optical image stabilizer is set to
[Normal]); Recording once every 30 seconds with full flash every second recording; Turning the camera off every 10 recordings;
The number of recordable images decreases in Auto Power LCD mode or Power LCD mode.
• CIPA is an abbreviation of "Camera & Imaging Products Association."
LUMIX G 14 mm / F2.5 ASPH.
Lens Construction 6 elements in 5 groups (3 Aspherical lenses)
Mount Micro Four Thirds mount
Optical Image Stabilizer -
Focal Length f = 14 mm (35 mm camera equivalent 28 mm)
Aperture Type 7 diaphragm blades / Circular aperture diaphragm
Aperture F2.5
Minimum Aperture F22
LENS Closest Focusing Distance 0.18 m / 0.59 feet
Maximum Magnification Approx. 0.1x / 0.2x (35 mm camera equivalent)
Diagonal Angle of View 75°
Filter Size ø 46 mm / 1.81 inch
Max. Diameter ø 55.5 mm / 2.19 inch
Overall Length Approx. 20.5 mm / 0.81 inch (from the tip of the lens to the base side of the lens mount)
Weight Approx. 55 g / 1.94 oz
Standard Accessories Lens cap, Lens rear cap, Lens storage bag
LUMIX G VARIO 14-42 mm / F3.5-5.6 ASPH. / MEGA O.I.S.
Lens Construction 12 elements in 9 groups (1 Aspherical lens)
Mount Micro Four Thirds mount
Optical Image Stabilizer YES
Focal Length f = 14 mm to 42 mm (35 mm camera equivalent 28 mm to 84 mm)
Aperture Type 7 diaphragm blades / Circular aperture diaphragm
Aperture Range F3.5 (Wide) - F5.6 (Tele)
Minimum Aperture F22
LENS Closest Focusing Distance 0.3 m / 1 feet
Maximum Magnification Approx. 0.16x / 0.32x (35 mm camera equivalent)
Diagonal Angle of View 75° (W) - 29° (T)
Filter Size ø 52 mm / 2.05 inch
Max. Diameter ø 60.6 mm / 2.39 inch
Overall Length Approx. 63.6 mm / 2.50 inch (from the tip of the lens to the base side of the lens mount)
Weight Approx. 165 g / 5.82 oz
Standard Accessories Lens cap, Lens hood, Lens rear cap, Lens storage bag
DMC-GF3 Battery Life When Recording HD Motion Pictures (Approx.)
AVCHD (FSH mode)
LUMIX G VARIO 14-42 mm / F3.5-5.6 ASPH. / MEGA O.I.S. LUMIX G 14 mm / F2.5 ASPH.
Continuous Recording Time AVCHD (FSH): 2 h 10 min AVCHD (FSH): 2 h 30 min
Actual Recording Time AVCHD (FSH): 1 h 5 min AVCHD (FSH): 1 h 15 min
•These are standard times taken at a temperature of 23ºC (73.4ºF) and a humidity of 50%RH. •The time available for recording varies
depending on the environment, the interval between recordings, and the manner of use. •Actual recordable time is the time available
for recording when repeating actions such as switching the power supply [ON]/[OFF], starting /stopping recording, zoom operation, etc.
•The length of recording time depends on the capacity of the SD/SDHC/SDXC Memory Card. (Up to the equivalent of 2 GB per motion
picture recording.) •Videos can be recorded continuously for up to 29 min 59 sec in European PAL areas. •The length of recording
time depends on the capacity of the SD/SDHC/SDXC Memory Card. •Use a card with SD Speed Class* with "Class 4" or higher when
recording videos in AVCHD. Also, use a card with SD Speed Class with "Class 6" or higher when recording videos in Motion JPEG.
* SD Speed Class is the speed standard regarding continuous writing.
Partial restrictions on using Panasonic digital video cameras to play AVCHD motion images recorded with the DMC-GF3.
•AVCHD motion images recorded with the image quality set to SH mode (1280 x 720) cannot be played on AVCHD-compatible digital video
cameras. •AVCHD motion images recorded with AVCHD-compatible digital video cameras cannot be played on the DMC-GF3.
•More detailed information is available on our support site: http://panasonic.jp/support/global/cs/dsc
About the performance of Face Recognition function
Recognition performance varies greatly depending on shooting conditions, i.e., according to factors such as angles, facial expression
and lighting, so operation under all conditions cannot be guaranteed. Because the camera searches for faces that are similar to
registered faces, there are cases where the faces are not correctly recognized when the registered image and the shooting image
varies much. When facial characteristics are similar, particularly between parents and their children or brothers and sisters, the
camera may not distinguish the faces.
•AVCHD motion images recorded onto an SD Memory Card or a DVD disc cannot be played from a device that does not support
the AVCHD standard. •AVCHD and AVCHD logos are trademarks of Panasonic Corporation and Sony Corporation. AVCHD is a
highdefinition (HD) digital video recording / playback format jointly established by Panasonic Corporation and Sony Corporation. For
more details, please refer to the "AVCHD Information Website". http://www.avchd-info.org/ •The release date may differ depending on
the country. Check the website of the Panasonic sales company in your country or region for details on the optional accessories that
are available in your market. •Batteries made by other companies which have been certified by Panasonic may be used with these
units, but we offer no guarantee as to the quality, performance or safety of such batteries. •Exercise care when purchasing batteries.
Many fake or imitation batteries have been found among those sold at unusually low prices and those which customers cannot check
for themselves before purchasing. •Please confirm the latest information about batteries on the following website. http://panasonic.
co.jp/pavc/global/cs/info/battery.html (English) •When a lens that does not support the contrast AF function is mounted, operation will
automatically switch to manual focus. Confirm the operation information of compatible lenses at Customer support http://panasonic.
jp/support/global/cs/dsc (English). •The SDXC/SDHC Memory Card can be used only if their logos are indicated on the equipment or
in the operation manual. It cannot be used with equipment that supports only the SD Memory Card. •Dolby and the double-D symbol
are trademarks of Dolby Laboratories. •HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC. •Microsoft and Windows are either registered trademarks or trademarks of Microsoft
® ®
Corporation in the United States and/or other countries. •Apple and Mac OS are either registered trademarks or trademarks of
® ®
Apple Inc. in the United States and/or other countries. •QuickTime and the QuickTime logo are trademarks or registered trademarks
of Apple Inc., used under license therefrom. •Four Thirds™ and Micro Four Thirds™, and Four Thirds and Micro Four Thirds Logo
marks are trademarks or registered trademarks of Olympus Imaging Corporation, in Japan, the United States, the European Union
and other countries. •Other names of systems and products mentioned in this brochure are generally the registered trademarks or
trademarks of the manufacturers who developed the system or product concerned. •Some accessories are not available in some
countries. •Weight and dimensions shown are approximate. •Design, functions, and specifications are subject to change without
notice. •Overall length of lens is from the tip of the lens to the base side of the lens mount. •Some functions may not work when
lenses other than the included lens are used. Please refer to Panasonic's website, etc., for the latest information. •Availability of
colors and OSD languages may vary depending on the sales area. •Some sample images are simulated. •The use of recorded or
printed materials that are protected by copyright for any purpose other than personal enjoyment is prohibited, as it would infringe
upon the rights of the copyright holder.
For Those Who Understand the Difference
