Byron Home Easy HE-208 Installation Instructions

HE-208 Remote Control
HOME
Ceiling Rose & Single Gang
easy
Light Switch
RE-INVENTING THE HOME
The HomeEasy HE-208 Remote Control
Bayonet Ceiling Rose allows and Single
gang light switch, allows you to convert a
standard single way light switch into a
2way switch, without the need for
additional wiring.
- 100W Max Load
Light Switch
- 30Metre Range
HE-307
For use with 1 gang incandescent lights, indoor use only.
INSTALLATION WARNINGS:
BEFORE COMMENCING INSTALLATION
ISOLATE YOUR MAINS ELECTRIC SUPPLY
Read the instructions care fully before starting the installation process and keep
them for future reference. If you are in any doubt on the installation process,
consult a qualified electrician.
This product should be installed in accordance with the relevant sections of
the building
regulations code, and the current edition of the IEE Wiring Regulations
(BS 7671:Requirements for electrical installations) and appropriate statutory
regulations.
Do not install ceiling receivers on lighting circuits used to supply other
products such as extractor fans and shaver socket outlets.
Do not exceed the Maximum Power Rating of 100W, Incandescent lighting
only
As of1 April 2004, new installations in the UK should be wired using the EU
harmonised colours for the supply conductors:
New colours:
BROWN = Live BLUE = Neutral Earth = Yellow/Green
Old colours:
RED = Live BLACK = Neutral
The old colours will cease from April 2006.
Electrical installations in bathrooms, kitchens, gardens, floor and heating systems,
swimming pools, saunas and extra-low voltage lighting are classed as special
installations and must be certified and conforming to Part P, requirements of
BS 7671:2001 and appropriate statutory regulations. Contact your local Building
Regulation authority if required.
V1.0
Installation Ceiling Rose:
Do not use the HE-206 Ceiling Rose with low voltage lighting transformers,
fluorescent bulbs, or energy saving lighting, incorrect installation may damage the
converter. In case of any doubt consult a competant electrical installer
1: Isolate the mains supply, then remove the existing ceiling rose.
2: Attach the HE-206 ceiling rose using the
Ceiling Rose
screws provided.
HE-206
3: Wire the mains cable to the HE-206 Ceiling Rose as per the
diagram opposite, making sure the Live and neutral wires are
correctly connected.
If required a breakable tab on the base can be removed.
4: Connect the all switch to the ceiling rose, making sure that the switch is zero
voltage.
Ceiling Rose
5:Make sure all the cables are connected correctly and securely fastened.
6: Now pair the HE-206 bayonet ceiling rose with a HomeEasy Remote control HE-100,
HE-200, HE-300 or HE-102 (Not Included).
See Pairing and Deleting Remote Control.
7: Replace the ceiling rose cover making sure no wires are caught between the switch
and the wall. Do not over tighten as this could crack or distort the cover. .
Com
1Way
Light Switch
