Byron Home Easy HE-206 Installation Instructions

HE-206 Remote Control
HOME
Bayonet Ceiling Rose
easy
RE-INVENTING THE HOME
The HomeEasy HE-206 remote control Bayonet Ceiling Rose allows you
to convert a standard ceiling rose in to a HomeEasy remote control unit.
For use with 1 gang incandescent lights only.
INSTALLATION WARNINGS:
BEFORE COMMENCING INSTALLATION
ISOLATE YOUR MAINS ELECTRIC SUPPLY
Read the instructions care fully before starting the installation process and keep
them for future reference. If you are in any doubt on the installation process,
consult a qualified electrician.
This product should be installed in accordance with the relevant sections of
the building
regulations code, and the current edition of the IEE Wiring Regulations
(BS 7671:Requirements for electrical installations) and appropriate statutory
regulations.
Do not install ceiling receivers on lighting circuits used to supply other
products such as extractor fans and shaver socket outlets.
Do not exceed the Maximum Power Rating of 100W, Incandescent lighting
only
As of1 April 2004, new installations in the UK should be wired using the EU
harmonised colours for the supply conductors:
New colours:
BROWN = Live BLUE = Neutral Earth = Yellow/Green
Old colours:
RED = Live BLACK = Neutral
The old colours will cease from April 2006.
Electrical installations in bathrooms, kitchens, gardens, floor and heating systems,
swimming pools, saunas and extra-low voltage lighting are classed as special
installations and must be certified and conforming to Part P, requirements of
BS 7671:2001 and appropriate statutory regulations. Contact your local Building
Regulation authority if required.
V1.0
Installation:
Do not use the HE-206 Ceiling Rose with low voltage lighting transformers,
fluorescent bulbs, or energy saving lighting, incorrect installation may damage
the converter. In case of any doubt consult a competant electrical installer
1: Isolate the mains supply, then remove the existing ceiling rose.
2: Attach the HE-206 ceiling rose using
the screws provided.
3: Wire the mains cable to the HE-206 Ceiling Rose as per the
diagram opposite, making sure the Live and neutral wires are
correctly connected.
If required a breakable tab on the base can be removed.
4: Connect the all switch to the ceiling rose, making sure that the switch is
zero voltage.
Ceiling Rose
5:Make sure all the cables are connected correctly and securely fastened.
6: Now pair the HE-206 bayonet ceiling rose with a HomeEasy Remote control
HE-100, HE-200, HE-300 or HE-102 (Not Included).
See Pairing and Deleting Remote Control.
7: Replace the ceiling rose cover making sure no wires are caught between the
switch and the wall. Do not over tighten as this could crack or distort the cover.
Com
1Way
Light Switch
