Byron Home Easy HE-202 Installation Instructions

HOME
easy
RE-INVENTING THE HOME
The HE-202 Dimmer Socket is an expansion
unit for the HomeEasy range of products
and is designed to work with all HomeEasy
remote controls.
Product Operation:
Pairing with Remote Control:
Up to Six remote control units can be paired with each receiver socket or
module. To program a socket insert the unit into a plug socket and switch on
the power, now press the "Learn" button. The LED will start to flash, now press
the selected "On" button on the remote control, the LED will stop flashing.
The units are now paired together, you can test this by pressing the selected
"On/Off" button
Always refer to the original instruction swhen using with additional products.
Deleting Remote Control:
To delete a remote control that has been paired with a HE202 receiver socket,
simply press the "Learn" button. The LED will start to blink; press the "Off"
button on the remote control, the LED will blink twice to confirm that the
remote control has been removed from the receiver sockets memory.
HE-202
Additional Dimmer
Socket
HOME
easy
300W Dimmer 300W Dimmer 300W Dimmer
Learn Button
LED
V1.0
Remote Socket reset:
To delete all the remote control units from the memory of the receiver
socket, hold the "Learn" button for more than 6 seconds, the LED will start
to blink continuously. Press and hold the "Learn" button again, the LED
will blink twice to confirm that all paired remote controls have been
deleted from the receiver sockets memory.
Dimming Receiver Sockets :
1. Using a paired remote control, Press the "On" button and press "On" again.
The unit will start the dimming cycle.
Never exceed 300W maximum load.
2. To set the receiver socket at the required level, press the "On" Button.
press "Off" to switch the receiver off.
Product Specification:
Remote Control: HE-202
Input: 230V ~50Hz
Range: 30 Metres (Open Distance)
Frequency: 433.92MHz
Max Load: 300W (Incandescent)
Indoor Use Only
Warning: Never Exceed the Product Specification
Contact:
Contact Details:
C H Byron
34, Sherwood Rd
Aston Fields
Bromsgrove
B60 3DR
Helpline: 0845 2301 231
Tel: 0845 2301231
Fax: 01527 557701
Web: www.chbyron.com
