Philips Calculite 8044 Specification

Page 1 of 2
14-5/8"
(372 mm)
5-1/4"
(289 mm)
(134 mm)
12-1/2"
(318 mm)
Top View
Ceiling Cutout: 8" (203 mm) Dia.
Reflector Trim
8044 CLW
Clear Iridescence Free, White Flange
8044 CLP Clear Iridescence Free, Polished Flange
8044 Add suffix. See options for other finishes.
Features
1. Optics: Directional prismatic glass spread lens and Alzak
direct light smoothly across and down wall. Rotates for correct orientation.
Aperture cone with Iridescence Free finish.
2. Socket Cup: Die-cast aluminum cup effectively dissipates heat and positions
lamp holder. Snaps onto reflector neck to assure consistently correct optical
alignment without tools.
3. Mounting Frame: Die-cast aluminum for dry or plaster ceilings.
4. Retaining Springs: Precision-tooled steel friction springs secure reflector to
mounting frame for quick, tool-less installation.
5. Mounting Brackets: 16 ga. steel. Adjust from inside of fixture. Use 3/4" or
1 1/2" lathing channel, 1/2" EMT, or optional mounting bars.
6. Ballast/J-Box: Outboard mounted to reduce heat transfer and maintain
lamp efficacy and life. Service from below without tools.
7. Torsiontite Springs: Wire formed steel holds reflector/spread lens
assembly snug to housing.
Electrical
Note: For ballast electrical data and latest lamp/ballast compatibility refer to
"Ballast" specification sheet for complete electrical data.
UL listed for through branch circuit wiring with max of (8) No. 12 AWG, 90° C
supply conductors.

Options and Accessories

Comfort Clear Finishes
Clear CCL
Diffuse CCD
CCZ
Champagne Bronze
CPW
Pewter
Specify desired flange
1
W White, P Polished
Blank - Molded Ring
Lightolier is a Philips group brand
6-3/4"
(171 mm)
3"
(76 mm)
11-3/8"
5
1" (25 mm) min.
2-1/8" (54 mm) max.
Frame-In Kit
S7218HU
S7226HU
Standard Dimming Options:
CU3
J1LD3
J2LD3
JUM7
J1MX
J2MX
Other dimming product available, please consult factory
"kick" reflector
®
Other Finishes
1
White WH
Calculite CFL Lensed Wall Washer
®
2
4
7-1/8" (181 mm) Dia.
8-5/8" Self-Flanged
(209 mm)
7" aperture, 2 lamp 18W Quad Tube CFL (120/277V) 2-pin and 4-pin
7" aperture, 2 lamp 26W Quad Tube CFL (120/277V) 2-pin and 4-pin
S7218H or S7226H
Lightolier PowerSpec 3% Dimming (120/277V)
Lutron 5% Dimming (120V)
Lutron 5% Dimming (277V)
Mark 7 Dimming (120/277V)
Mark 10 Dimming (120V)
Mark 10 Dimming (277V)
Options and Accessories (continued)
Emergency
Chicago Plenum
Existing/Thk. Ceiling
Emergency Ltg. Kit
Fuse (Slow Blow)
*See Spec. Sheets:
Mounting Bars & Accessories; see Specification Sheet MBA.
Sloped Ceiling Adapters; see Specification Sheet SCA.
Labels
UL listed for damp locations, I.B.E.W.
Alzak is a registered trademark of ALCOA.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • F0711
7" Aperture (2) Quad Tube Wall Washer
7
1-1/8" (29 mm) max.
Ceiling Thickness
3
1
Add Suffix EM*
Add Suffix LC
FA EC7*
FA EM3E* (4 pin)
FA EM4E* (4 pin)
FA EM2T* (2 pin)
Add Suffix F
FAEC, FAEM
Type:
8044
6
