Lightolier Lytespan 9630 Specification

Page 1 of 1
4
2 1/2"
Ordering Information
Catalog No.
9630WH
9630BK
Features
1. Lytespan attachment fitting: Die-cast zinc alloy.
2. Housing: .40" aluminum
3. Step baffle: Compression-molded high heat phenolic with stepped conical
surface for low brightness. Integral black finish.
4. Lever: Locks attachment fitting electrically and mechanically anywhere
along the track.
5. Movable brass Contact: Extends for connection to 2nd circuit in Advent
Lytespan Track.
6. Swivel: Die-cast zinc alloy. 350° horizontal adjustment.
7. Pivot mounting: Tensioned with built-in stop, provides 90° vertical
adjustment.
Electrical
Porcelain socket, medium base, nickel plated screw shell. No. 18 braided SF-1
leads.
1
6
3 1/4"
7
5"
7"
Finishes
Matte White
Matte Black
Lytespan
2
4 1/2"
3
Mounting
All Lytespan Track Systems
9630 SPEC SHEET
Finish
All painted finishes baked enamel.
Labels
UL, I.B.E.W.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • A1006
Track Lighting
®
Classics Step Cylinder PAR30
Lamps
A19, PAR16
PAR30 75W Max
Type:
www.lightolier.com
9630
