RECHARGEABLE
SET up And OpERATInG InSTRuCTIOnS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MAnuAL.
©
Copyright
2008 by Harbor Freight Tools
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
WORKLIGHT
60 LEd
Model
3491 Mission Oaks Blvd., Camarillo, CA 93011
98113
®
. All rights reserved. No portion of this
®
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 98113 and is the answer not in the manual?

Questions and answers

Related Manuals for Chicago Electric 98113

Summary of Contents for Chicago Electric 98113

  • Page 1 RECHARGEABLE WORKLIGHT 60 LEd Model 98113 SET up And OpERATInG InSTRuCTIOnS Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. ® distributed exclusively by Harbor Freight Tools 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our website at: http://www.harborfreight.com Read this material before using this product.

  • Page 2: Important Safety Information

    SAVE THIS MAnuAL nOTICE is used to address practices Keep this manual for the safety warn- not related to personal injury. ings and precautions, assembly, operat- CAuTIOn, without ing, inspection, maintenance and cleaning the safety alert procedures. Write the product’s serial symbol, is used to address number in the back of the manual near the practices not related to...
  • Page 3 Worklight. Unmodified plugs and prevent unintentional starting. Ensure the power Switch (10) is matching outlets will reduce risk of in the off-position before connect- electric shock. ing to power source and/or battery Avoid body contact with grounded pack, picking up or carrying the surfaces such as pipes, radiators, tool.
  • Page 4 Maintain the Worklight. Check for will ensure that the safety of the tool misalignment or binding of moving is maintained. parts, breakage of parts and any Specific Safety Warnings other condition that may affect the Worklight’s operation. If damaged, Maintain labels and nameplates on have the Worklight repaired before the Worklight.
  • Page 5 SAVE THESE obstruct air flow under the Adapt- ers. InSTRuCTIOnS. Place the Adapters on a stable, solid, nonflammable surface (such as a stable metal workbench or concrete GROundInG floor) at least 1 foot away from all flammable objects, such as drapes, TO pREVEnT walls, and car seats.

  • Page 6: Specifications

    SpECIFICATIOnS double Insulated Tools: Tools with Two prong AC plugs Input: 120 VAC~ / 60 Hz / or 12 VDC Output: 12 VDC @ 400mA 120 VAC, AC/DC Adapter: 2 Prong, Grounded VDC Cigarette Lighter Adapter, Grounded Battery Type: 7.2V, 900Ah, Ni-MH Rechargeable Electrical (Not Replaceable)
  • Page 7 TO pREVEnT charging process. Then plug the AC/ SERIOuS InjuRY DC Adapter into the nearest 120 volt, FROM ACCIdEnTAL grounded, electrical outlet. OpERATIOn: IMPORTANT: The initial charge time Turn the power Switch to its for the Battery Pack is 10 hours. off position and disconnect Thereafter, the charge times are 6 the Adapter Cord from its...

  • Page 8: Maintenance And Servicing

    To Charge the Battery pack using the the Power Switch again to its “OFF” Cigarette Lighter Adapter: position. (See Figure A.) Prior to recharging, allow the battery The Worklight is designed to operate to cool completely. (on a fully charged Battery Pack) for approximately 6 hours before re- To charge the Battery Pack (12) of charging is required.

  • Page 9: Inspection, Maintenance, And Cleaning

    InSpECTIOn, MAInTEnAnCE, And CLEAnInG pLEASE REAd THE BEFORE EACH USE: Inspect the FOLLOWInG CAREFuLLY general condition of the Worklight. Check for loose screws, misalignment THE MANUFACTURER AND/OR or binding of moving parts, cracked or DISTRIBUTOR HAS PROVIDED THE broken parts and any other condition PARTS LIST AND ASSEMBLY DIAGRAM that may affect its safe operation.

  • Page 10: Troubleshooting

    TROuBLESHOOTInG problem possible Cause possible Solution Worklight does not turn on. Power Switch not on. Press Power Switch to ON position. Battery Pack is low. Recharge Battery Pack. Battery Pack not charging. Check AC/DC Adapter/Cigarette Lighter Adapter connections from power supply source to Worklight.

  • Page 11: Limited 90-Day Warranty

    LIMITEd 90 dAY WARRAnTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
