Service Manual
Color Plasma Display Monitor
Model
CMP5000WXU
CMP5000WXJ
READ THE INSTRUCTIONS INSIDE CAREFULLY.
KEEP THIS USER MANUAL FOR FUTURE REFERENCE.
For future reference, record the serial number of your monitor.
SERIAL NO.
The serial number is located on the rear of the monitor.
Contents related to system specifications, power requirements,
accessories, and other information differ with respect to the
country where this unit is purchased. For customers living in the
U.S.A. or Canada, please use and refer to the instructions written
in either English or French. For customers in Japan, please use
and refer to the instructions written in Japanese.
Les caractéristiques, les spécifications d'alimentation, les
accessoires et d'autres informations diffèrent d'un pays à
l'autre. Si vous vivez au Canada ou aux États-Unis, reportez-
vous aux instructions en français ou en anglais. Si vous vivez
au Japon, reportez-vous aux instructions en japonais.
USER'S MANUAL
MANUEL UTILISATEUR
Advertisement
Table of Contents
Related Manuals for Hitachi CMP5000WXJ
Summary of Contents for Hitachi CMP5000WXJ
- Page 1 Color Plasma Display Monitor USER'S MANUAL Model MANUEL UTILISATEUR CMP5000WXU CMP5000WXJ READ THE INSTRUCTIONS INSIDE CAREFULLY. KEEP THIS USER MANUAL FOR FUTURE REFERENCE. For future reference, record the serial number of your monitor. SERIAL NO. The serial number is located on the rear of the monitor. Contents related to system specifications, power requirements, accessories, and other information differ with respect to the country where this unit is purchased.
- Page 2 English This unit has been designed for use as a computer display monitor. The optional video card is required if you wish to view other video signals on the monitor. For details consult your local retail dealer. Français Cet appareil est conçu pour une utilisation comme moniteur d’affichage d’ordinateur.
- Page 3 USER’S MANUAL Thank you very much for purchasing the HITACHI Plasma Display Monitor. Before using your monitor, please carefully read the “SAFETY GUIDELINES” and this “USER’S MANUAL” so you will know how to operate the monitor properly. Keep this manual in a safe place. You will find it useful in the future.
- Page 4 ¶ Power-Saving Design This display achieves the lowest power consumption in the ® As an E Partner, Hitachi, Ltd. has NERGY industry for screens in the 50" XGA class (380 W). Further, use of ® determined that this product meets the E...
-
Page 5: Table Of Contents
Contents SAFETY GUIDELINES ..........I - IV Before Proceeding ............2 How to Use This Manual .............. 2 Checking Supplied Accessories ........... 3 Part Names and Functions ........4 Main Unit ..................4 Remote Control Unit ..............5 Connection Panel ................6 Installation and Connections ........ -
Page 6: Safety Guidelines
SAFETY GUIDELINES This monitor is designed to be safe to use. However, fire or serious injury may occur unless you use this monitor in the proper way. Please follow the instructions shown below in order to avoid injury. Keep the safety guideline Do not use the monitor if it fails If you find something unusual , (1) Turn off the monitor... - Page 7 SAFETY GUIDELINES(continued) WARNING Fire or electric shock may cause death or serious injury unless you follow the instruction. • The enclosed power cord must be used! Failure to do so may cause electric shock hazard or fire hazard. In USA/Canada, use a UL LISTED/CSA LABELLED or CERTIFIED power cord set meeting the following specifications : Rating: min.
- Page 8 PRECAUTIONS • Installation environment Do not obstruct a ventilation hole. Do not put the monitor on carpet or blanket, or near a curtain which has a possibility of obstructing a ventilation hole of the monitor. Do not put the monitor in the following places. •...
- Page 9 According to 47CFR, Part 2 and 15 for Class B Personal Computers and Peripherals; and / or CPU Boards and Power Supplies used with Class B Personal Computers: Hitachi America, Ltd. Computer Division Located at: 2000 Sierra Point Parkway, Brisbane,CA 94005-1835, U.S.A. Telephone: 1-800-HITACHI Declare under sole responsibility that the product identified herein, complies with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device.
-
Page 10: Before Proceeding
Before Proceeding Press MENU to display the menu screen. How to Use This Manual MAIN MENU INPUT1 PICTURE SCREEN SET UP OPTION CO NT RA S T This manual is set up to follow the course of actions and I GHT . operations in the order that would seem most logical for R L E V E L : 6 0... -
Page 11: Checking Supplied Accessories
Before Proceeding Checking Supplied Accessories Check that the following accessories were supplied. Power cord Remote control unit AA (R6) batteries (x 2) Speed clamps (x 2) Bead bands (x 2) ÷ USER’S MANUAL... -
Page 12: Part Names And Functions
Part Names and Functions Main Unit Operation panel on the main unit Main unit Note When optional speakers have been connected, the operation panel on the main unit will not be operable. Main unit MENU button Remote control sensor Press to open and close the on-screen menu (pages Point the remote control toward the remote sensor to 14 to 26). -
Page 13: Remote Control Unit
Part Names and Functions Remote Control Unit SCREEN SIZE button Press to select the screen size (page 18). INPUT buttons Use to select the input (page 16). MENU button Press to open and close the on-screen menu (pages 14 to 26). ADJUST (5/∞/3/2) buttons Use to navigate menu screens and to adjust various settings on the unit. -
Page 14: Connection Panel
Part Names and Functions Operating range of the remote Connection Panel control unit When operating the remote control unit, point it at the The connection panel is provided with two video input remote sensor located on the front panel of the main jacks and one video output jack. - Page 15 Part Names and Functions AC INLET SPEAKER – INPUT1 INPUT2 AUDIO CONTROL COMBINATION RS-232C (ON SYNC) (H/V SYNC) OUTPUT INPUT OUTPUT SPEAKER ANALOG RGB (ANALOG RGB) – (INPUT1/2) Ô 89 0 Synchronizing signal impedance selector switch MAIN POWER switch Depending on the connections made at INPUT2, it Use to switch the main power of the unit on and off.
-
Page 16: Installation And Connections
÷ When possible, please install using parts and accessories manufactured by HITACHI. HITACHI will not be held responsible for accident or damage caused by the use of parts and accessories manufactured by other companies. -
Page 17: Connection To Input1 And Input2
Installation and Connections Connection to a personal Connection to INPUT1 and INPUT2 computer The INPUT 1 and INPUT 2 jacks are used to connect the display to a computer. After making the connections, Connection method differs depending on the computer adjust the screen settings in accordance with the type. - Page 18 Installation and Connections When connecting to INPUT1 Connection of G ON SYNC analog RGB source Make G ON SYNC connections for a personal computer with output that has the synchronization signal layered on INPUT1 OUTPUT ANALOG RGB (ANALOG RGB) top of the green signal. When connecting to INPUT1 INPUT1 OUTPUT...
-
Page 19: Audio Connections
Installation and Connections Connection of composite SYNC analog RGB Audio Connections source Before making connections, be sure to check that the Make composite SYNC connections for a personal audio component’s power and the unit’s main power is computer with output that has the vertical off. -
Page 20: Power Cord Connection
Installation and Connections Power Cord Connection Connect the power cord after all component connections have been completed. Connect the power cord to this unit. Plug the power cord into a power outlet. CAUTION ÷ Use only the power cord provided. ÷... -
Page 21: How To Route Cables
Installation and Connections How to Route Cables Speed clamps and bead bands are included with this unit for bunching cables together. Once components are connected, follow the following steps to route cables. * As viewed from the rear of the display. Bunch separated cables together and secure Organize cables together using the provided them with the provided bead bands. -
Page 22: Setting Up The System
Setting Up the System Setup after Connection Press 5/∞ to select SETTING, then press SET. MAIN MENU INPUT1 PICTURE SCREEN SET UP OPTION After components have been connected to INPUT1 or I N P UT I N P UT 1 INPUT2, on-screen setup is necessary. - Page 23 Setting Up the System CLAMP POSITION setup Press SET to select LOCKED. MAIN MENU INPUT1 Depending on the signal, analog RGB signals may result PICTURE SCREEN SET UP OPTION I N P UT I N P UT 1 in the screen image appearing with a whitish or greenish POWE R M NA GEME OF F...
-
Page 24: Operations
Operations Press INPUT on the remote control unit or the Selecting an Input Source main unit to select the input. Input changes each time the main unit’s INPUT is pressed as follows. This section explains the basic operation of this unit. 3 INPUT1 Outlined on the following pages is how to turn the main power on and off, put this unit in the operation or standby... -
Page 25: To Adjust The Volume
Operations To adjust the volume To confirm display settings DISPLAY VOLUME +/– Press VOLUME on the remote control unit. Use VOLUME + or VOLUME – to adjust the volume of the connected speakers. Press DISPLAY on the remote control unit. The currently selected input, screen size and refresh rates will be displayed for about 3 seconds. -
Page 26: Screen Size Selection
Operations During personal computer signal input Screen Size Selection 1 DOT BY DOT The input signal and the screen maintain a dot to line ratio of 1:1 and is thus highly faithful to the source. This unit incorporates screen modes of various height and width ratios. -
Page 27: Partial Image Enlargement (Point Zoom)
Operations Press SET to select the zoom ratio. Partial Image Enlargement Pressing SET repeatedly changes the zoom ratio in the following order: (POINT ZOOM) 3 x 1.5 3 x 2.0 x 4.0 2 x 3.0 2 This display allows any one of nine screen areas (AREA 1 to AREA 9) to be selected and enlarged to x1.5, x2, x3, or x4. -
Page 28: Automatic Power Off
Operations Press 5/∞ to select either the POWER Automatic Power OFF MANAGEMENT or AUTO POWER OFF mode. [When using INPUT 1] This display is equipped with automatic power- MAIN MENU INPUT1 management and auto-power-off functions, which allow PICTURE SCREEN SET UP OPTION the unit to automatically switch to power-saving mode I N P UT... -
Page 29: Display Panel Adjustments
Display Panel Adjustments PICTURE mode adjustment items Adjusting the Picture Quality Below are brief descriptions of the options that can be set in the PICTURE mode. Press MENU to display the menu screen. CONTRAST ············· Adjust according to the surrounding MAIN MENU INPUT1 brightness so that the picture can be... -
Page 30: Adjusting The Image Position And Clock (Automatic Adjustment)
Display Panel Adjustments Adjusting the Image Position and Clock (Automatic Adjustment) Pressing AUTO SET UP on either the main unit or the remote control unit will adjust the screen position and clock to optimum values. Note Perform this adjustment individually for each input function (INPUT 1, INPUT 2), and each signal type. -
Page 31: Manual Adjustment Of Screen Position And Clock
Display Panel Adjustments Press SET. Manual Adjustment of Screen Pressing SET writes the value into the memory and returns the display to the step 3 screen. Position and Clock When adjustment is finished, press MENU to exit the menu screen. Press MENU to display the menu screen. -
Page 32: Other Operations
Other Operations Press 2/3/5/∞ to select the first desired Rewriting the Input Display character (here, “C”), then press SET to confirm (INPUT LABEL) (repeat this step to input up to eight desired characters.) MAIN MENU INPUT1 This function allows rewriting of the screen contents displayed with differing inputs. -
Page 33: Power Control Function
Other Operations Power Control Function AUTO FUNCTION The power control function allows screen brightness to This display is equipped with an optional AUTO be suppressed as a means of lowering power FUNCTION selector. When enabled, the selector consumption and reducing display deterioration. automatically switches the display’s input source to INPUT 1 when an image signal is detected at the INPUT 1 Press MENU to display the menu screen. -
Page 34: Audio Output (Audio Out)
Other Operations Press 2/3 to select OPTION. Press SET to select INPUT 1. The factory default setting is OFF. Each time SET is MAIN MENU INPUT1 pressed the selector function switches alternately as PICTURE SCREEN SET UP OPTION shown: POWE R S T A A RD A U T O... -
Page 35: Additional Information
Additional Information Cleaning Troubleshooting What may at first seem to be an malfunction, may be Regular cleaning will extend the life and performance of remedied with a quick check. this unit. The recommended way to clean the display and Please check to see if a warning is displayed on the related parts is described below. -
Page 36: General Problems
Additional Information General problems Problem Possible Solution • No power • Is the power cord disconnected? (page 12) • Has the MAIN POWER switch been switched on? (page 7) • External influences such as lightning, static electricity, etc., may cause improper operation. In this •... - Page 37 Additional Information Although this unit incorporates high precision technology About the plasma panel’s in its design, please understand that there may be protection function extremely slight pixel breakup, or light emission fault. The brightness of this display will deteriorate slightly Note when an image with little movement such as a In order to protect the panel and internal circuitry, this display is...
-
Page 38: Specifications
Additional Information Specifications Audio Input AUDIO INPUT (for INPUT 1/2) Stereo mini jack General L/R ... 500mVrms/more than 10 k Light emission panel .... 50 inch plasma display panel Output AUDIO OUTPUT Number of pixels ..........1280 x 768 Stereo mini jack Power supply ...... -
Page 39: Supplement 1
Additional Information Supplement 1 PC signal compatibilty table (INPUT1, INPUT2) Refresh rate Screen size (Dot x line) Resolution Remarks (Dot x Line) Vertical Horizontal DOT BY DOT FULL PARTIAL 56.4Hz 24.8kHz NEC PC-9800 640x400 1280x768 ± 70.1Hz 31.5kHz NEC PC-9800 31.5kHz 60Hz (852x480) -
Page 40: Supplement 2
Additional Information Supplement 2 Explanation of Terms Signal assignment of INPUT 1 (Mini D-sub 15 pin Aspect ratio socket connector) The TV screen’s width to height ratio is referred to as its aspect ratio. The aspect ratio on standard TVs is 4:3 and on wide TVs or High Definition TVs it is 16:9. -
Page 41: Installation Instructions
Model CMPAD06 Installation Instructions Thank you for purchasing the Hitachi Plasma Display Table top Stand. To ensure correct usage, please read this instruction manual thoroughly. After reading, please store this manual in a safe place for future reference. This plasma display tabletop stand is for use only with the following model: CMP5000WX Request an installation specialist to install this unit. - Page 42 Usage cautions to ensure correct usage The following symbols are used to ensure safe usage of the product, to prevent danger Symbols to yourself and other parties and to prevent damage to property. This symbol indicates that incorrect handling due to ignoring this symbol WARNING can result in the possibility of personal injury or even death.
-
Page 43: Stand Assembling
Stand assembling Screws (4 x 8) Turn the base cover over so the underside is facing up. Stand pipe Insert the stand pipes into the base cover. Use the included screws to stabilize the Screws (4 x 8) stand pipes. Stand pipe Base cover Stand attaching to the Plasma Display... - Page 44 Stand attaching to the Plasma Display Step 2. As shown in figure, hook the stand pipe holes onto the screw heads of the installation bolts 1, then slide the stand upwards to the main plasma display until it engages the installation bolts 1 (once put together with the display, the stand will slides no more than 19 mm (3/4 inch)).
- Page 45 After assembling, connect the stand to the floor to prevent from falling over. Stabilizing to the floor Sample use of the stabilization bolts • Use screws (sold separately) to attach and stabilize the 1. Attach the stabilization bolts that come with the plasma stand.
- Page 46 Specificatio 566 (W) x 508 (H) x 339 (D) mm Dimensions (22-5/16 (W) x 20 (H) x 13-3/8 (D) in.) 4.0 kg (8.82 lb) Weight 42.9 kg (94.58 lb) (When the 50 inch plasma display is attached) Main material/ Steel sheet Surface treatment Dimensions Diagram Normal use (without optional speakers)
-
Page 47: Wall Mount Unit (Cmpak06)
Model CMPAK06 Installation Instructions Thank you for purchasing the Hitachi Plasma Display Wall-mount Unit. To ensure correct usage, please read this instruction manual thoroughly. After reading, please store this manual in a safe place for future reference. This plasma display wall-mount unit is for use only with the following model: CMP5000WX Special techniques are necessary for installation of the plasma display. - Page 48 Usage cautions to ensure correct usage Symbols The following symbols are used to ensure safe usage of the product, to prevent danger to yourself and other parties and to prevent damage to property. This symbol indicates that incorrect handling due to ignoring this symbol WARNING can result in the possibility of personal injury or even death.
-
Page 49: Installation Location
Installation Location WARNING The wall where the wall-mount unit is to be Plaster board or thin ply wood, etc. installed must be capable of long-term support of the total load of the plasma display and wall-mount unit. Measures should also be taken to ensure sufficient strength to withstand the force of earthquakes, vibration and other external forces. - Page 50 CAUTION Do not install in Do not install where locations where there is direct there is excessive sunlight and other vibration or impact. strong light. Injury and damage Strong light could result could result from in eye fatigue during falling. usage.
-
Page 51: Installation Procedure
Installation Method Installation procedure Be sure to install the speaker at this stage. Remove the special screws (2 locations) from the For the installation method, refer to the speaker installation bottom of the hung on wall unit. procedure in the speaker user manual. Attach the wall side hardware to the wall. -
Page 52: Angle Setup
Installation Method Angle setup This installation hardware allows the display to be directed downwards freely at any angle from the vertical to 25ˇ. This adjustment must always be done by 2 people. Adjust the angle by rotating the screws at the center top and center bottom of the wall side hardware to the left or right. If the angle is increased while you are adjusting the angle using the screw at the center of the bottom, it is difficult to turn the screw. -
Page 53: Product Specifications
Product Specifications External Dimensions (258) (143) (314) (314) (239) 6-23x10.5 6-φ10.5 1218 (Without side speaker) 1368 (With side speaker) Mass 13.8kg Main material Steel sheet Surface treatment Black baked paint Products mounted CMP5000WX... -
Page 54: Speaker Systems (Cmpas05)
Speaker Systems for Hitachi Plasma Display Monitor CMP5000WX Model CMPAS05 User Manual READ THE INSTRUCTIONS ON THIS USER MANUAL CAREFULLY. KEEP THIS USER MANUAL FOR FUTURE REFERENCES. DO NOT HANDLE THE MONITOR BY HOLDING THE SPEAKER SYSTEMS. Please handle the speakers with sufficient care, as the grille net and the cabinet can become damaged or broken when they are subjected to strong external impacts. -
Page 55: Installation On The Plasma Display
Installation on the plasma display Perform installation according to the following steps 1 to 3. NOTE: After this unit has been installed on the plasma display, you can't use the display operation panel. Please use the remote control supplied with the display. Attach the mounting plates to this unit Install this unit on the display side As in the illustration below (right speaker only), when looking... -
Page 56: Plasma Display
CONNECTION TO A Installation to commercial Plasma Display mounting fittings This unit includes M8 (ø 25) Switch off the power of the plasma display. washers for installation on commercial mounting fittings. Washer M8 Connect the input terminals of the speaker (ø... - Page 57 Hitachi, Ltd. Tokyo, Japan International Sales Division THE HITACHI ATAGO BUILDING, No. 15 –12 Nishi Shinbashi, 2 – Chome, Minato – Ku, Tokyo 105-8430, Japan. Tel: 03 35022111 HITACHI EUROPE LTD. HITACHI EUROPE S.A. Dukes Meadow 364, Kifissias Ave. & 1, Delfon Str.
