Service Manual
Models: 1.0, 1.3, and 1.5
This manual must only be
WARNING
used by a qualified heating
installer / service technician.
Read
including this manual and the
Armor X2 Installation and
Operation Manual, before
installing. Perform steps in
the order given. Failure to
comply could result in severe
personal injury, death, or
substantial property damage.
Save this manual for future reference.
AWX2-SER Rev A
all
instructions,
