Epson DC-06 Document Camera

Quick Start

You can connect the DC-06 document camera directly to most Epson projectors.
For other projectors, you need to connect through your computer and install
the ArcSoft
Application software for ELPDC06.
®
Setting Up the
Document Camera
1
Raise the camera head and rotate the foot.
2
Lift the arm.
3
Raise and rotate the arm.
4
Connect the USB cable that came with the camera to your projector
or computer.
Direct connection to Epson projector
Connection through computer (requires ArcSoft Application software for ELPDC06)
Using the
Document Camera
You can use the document camera to capture or project pages from books or
other documents, or even three-dimensional objects.
1
Place the book, document, or object under the camera head. If necessary,
press the Source Search button on the camera to switch the
projector's display.
2
Raise or lower the arm to adjust the image size. Press the Focus button to
automatically focus the image.
To rotate the image, turn the dial on the camera head.
To zoom in on part of the image, press the
button to zoom out.
To illuminate the image, press the
To display live action or an image from a whiteboard, chalkboard, or
wall, rotate the camera head.
Source Search button
Focus button
button. Press the
button.
