Elmo Visual Presenter EV-200 Instruction Manual page 9

No. Name
Camera Head
1
Arm
2
Base Unit
3
Main Stage
4
Auxiliary Stage
5
Shutter Switch
6
[SHUTTER]
Image Input Selection
7
Switch [INPUT]
Power Switch [POWER]
8
Power Terminal
9
[DC IN 12V]
Accessory Case
10
Video Cable
11
AC Adapter
12
Function
Moving up/down the camera head can change the
size of an object in display on the monitor screen
smoothly.
A link part for moving the camera head horizontally.
A base part of the Presenter.
A stage for placing an object thereon.
Use this stage, if necessary, according to the object
size.
Shutter ON/OFF switch.
In normal use, this switch is set at OFF.
If the image is too bright after adjusting the gain,
turn the switch ON.
Note: - If the shutter is turned ON when the
brightness of the image is suitable,
noise may appear in the image.
To switch the image output from the Composit-
Video-out terminal [VIDEO OUT].
[VIDEO IN] . . Image via the Composit-Video-in
terminal [VIDEO INPUT]
[MAIN] . . . . . Image via the main camera
Note: - The image output from S-video-out
terminal [S -VIDEO OUT] is not
switched.
Power ON/OFF switch.
The DC jack of the AC adaptor is inserted into this
terminal (12VDC).
A case for housing the AC adaptor and video cable
exclusively. When the Presenter is stored, house this
case inside the stage.
To connect the Presenter to the monitor TV.
To connect the Presenter to an outlet (120VAC).
- 8 -
