Frigidaire FRT18P6BS Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT18P6BS:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18P6BSB0
FRT18P6BS
FRT18P6BSK0
FRT18P6BS
MARKET
North America
ENERGY GUIDE - # 218791412
OWNER'S GUIDE - # 240400107
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
stain/blk
R134a
stain/blk
Publication No.
5995383519
030103
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18P6BS
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18P6BS
Summary of Contents for Frigidaire FRT18P6BS
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18P6BSB0 FRT18P6BS R134a stain/blk FRT18P6BSK0 FRT18P6BS R134a stain/blk MARKET North America ENERGY GUIDE - # 218791412 OWNER’S GUIDE - # 240400107 SERVICE DATA SHEET - # 240379010 TOP MOUNT REFRIGERATOR Model No.
- Page 2 Publication No. FRT18P6BS 5995383519 DOOR 12/02...
- Page 3 FRT18P6BS Publication No. 5995383519 DOOR A = FRT18P6BS (FRT18P6BSB0) B = FRT18P6BS (FRT18P6BSK0) POS. NO PART NO DESCRIPTION 240542109 Gasket-frzr door,black ,magnetic 240542112 Gasket-refr door,black ,magnetic 240534901 Rack-door 240534701 Rack-door,4B 240337703 Door-dairy,w/o graphics ,clear 240534801 Rack-door 240412503 Door-frzr,stainless ,complete assy 240412504 Door-frzr,stainless ,complete assy 240415204...
- Page 4 Publication No. FRT18P6BS 5995383519 CABINET 12/02...
- Page 5 FRT18P6BS Publication No. 5995383519 CABINET A = FRT18P6BS (FRT18P6BSB0) B = FRT18P6BS (FRT18P6BSK0) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462008 Cover-evap coil 240532102 Seal-coil cover...
- Page 6 Publication No. FRT18P6BS 5995383519 SHELVES 12/02...
- Page 7 FRT18P6BS Publication No. 5995383519 SHELVES A = FRT18P6BS (FRT18P6BSB0) B = FRT18P6BS (FRT18P6BSK0) POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358002 Shelf-freezer,full width 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 16 # 241500701 Socket-light/lamp...
- Page 8 Publication No. FRT18P6BS 5995383519 SYSTEM 12/02...
- Page 9 FRT18P6BS Publication No. 5995383519 SYSTEM A = FRT18P6BS (FRT18P6BSB0) B = FRT18P6BS (FRT18P6BSK0) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness,machine compt ,w/electric cord 6* # 240388701 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 14 # 5303918208 Defrost Heater Kit...
-
Page 10: Wiring Schematic
Publication No. FRT18P6BS 5995383519 WIRING SCHEMATIC 12/02... -
Page 11: Wiring Diagram
FRT18P6BS Publication No. 5995383519 WIRING DIAGRAM # = Fast-moving Parts 12/02 * = Non-Illustrated Parts...
