Frigidaire FRT18P5A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18P5A
  6. Factory parts catalog

Frigidaire FRT18P5A Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT18P5A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18P5AB3
FRT18P5A
FRT18P5AQ1
FRT18P5A
FRT18P5AQ3
FRT18P5A
FRT18P5AW1
FRT18P5A
FRT18P5AW3
FRT18P5A
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995369328
020401
-EN/SERVICE/DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18P5A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18P5A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18P5A

Summary of Contents for Frigidaire FRT18P5A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18P5AB3 FRT18P5A R134a black FRT18P5AQ1 FRT18P5A R134a bisque FRT18P5AQ3 FRT18P5A R134a bisque FRT18P5AW1 FRT18P5A R134a white FRT18P5AW3 FRT18P5A R134a white MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379007 TOP MOUNT REFRIGERATOR...
