Frigidaire FRT18P6BS Factory Parts Catalog

Frigidaire FRT18P6BS Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT18P6BS:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18P6BSK5
FRT18P6BS
MARKET
North America
ENERGY GUIDE - 218791412
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS,INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a dynamic
stainless/black
Publication No.
5995378691
020924
-EN/SERVICE /DCS
357
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18P6BS
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18P6BS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT18P6BS

Summary of Contents for Frigidaire FRT18P6BS

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18P6BSK5 FRT18P6BS R134a dynamic stainless/black MARKET North America ENERGY GUIDE - 218791412 OWNER’S GUIDE - 240400105 TOP MOUNT SERVICE DATA SHEET - 240379010 REFRIGERATOR Model No. FRT18P6BS ELECTROLUX HOME PRODUCTS,INC. P.O.
