Frigidaire FRT18P5A Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT18P5A:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18P5AB9
FRT18P5A
FRT18P5AQ9
FRT18P5A
FRT18P5AW9
FRT18P5A
MARKET
North America
WIRING DIAGRAM - # 240379010
OWNER'S GUIDE - # 240400106
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995379723
021014
-EN/SERVICE /DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18P5A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18P5A
Summary of Contents for Frigidaire FRT18P5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18P5AB9 FRT18P5A R134a black FRT18P5AQ9 FRT18P5A R134a bisque FRT18P5AW9 FRT18P5A R134a white MARKET North America WIRING DIAGRAM - # 240379010 OWNER’S GUIDE - # 240400106 SERVICE DATA SHEET - # 240379010 TOP MOUNT REFRIGERATOR Model No.
- Page 2 Publication No. FRT18P5A 5995379723 DOOR 10/02...
- Page 3 FRT18P5A Publication No. 5995379723 DOOR A = FRT18P5A (FRT18P5AB9) B = FRT18P5A (FRT18P5AQ9) C = FRT18P5A (FRT18P5AW9) POS. NO PART NO DESCRIPTION 240514609 A - - Gasket,frzr door seal ,black ,magnetic 240514605 - B C Gasket,frzr door seal ,white ,magnetic 240514612 A - - Gasket,seal ,black ,refr door ,magnetic...
- Page 4 Publication No. FRT18P5A 5995379723 CABINET 10/02...
- Page 5 FRT18P5A Publication No. 5995379723 CABINET A = FRT18P5A (FRT18P5AB9) B = FRT18P5A (FRT18P5AQ9) C = FRT18P5A (FRT18P5AW9) POS. NO PART NO DESCRIPTION 240355401 A B C Cover-fan 240367001 A B C Knob-damper control 5303001028 A B C Nut,push-on 240367401 A B C Damper-fan cover 5308000010 A B C...
- Page 6 Publication No. FRT18P5A 5995379723 SHELVES 10/02...
- Page 7 FRT18P5A Publication No. 5995379723 SHELVES A = FRT18P5A (FRT18P5AB9) B = FRT18P5A (FRT18P5AQ9) C = FRT18P5A (FRT18P5AW9) POS. NO PART NO DESCRIPTION 215667501 A B C Tray,ice cube ,plastic 240358002 A B C Shelf-freezer,full width 240362502 A B C Diffuser,air ,top 240362601 A B C Diffuser,air ,bottom...
- Page 8 Publication No. FRT18P5A 5995379723 SYSTEM 10/02...
- Page 9 FRT18P5A Publication No. 5995379723 SYSTEM A = FRT18P5A (FRT18P5AB9) B = FRT18P5A (FRT18P5AQ9) C = FRT18P5A (FRT18P5AW9) POS. NO PART NO DESCRIPTION 240444401 A B C Condenser,dynamic 218944001 A B C Drier-filter,R134a System 240496101 A B C Wiring Harness,machine compt ,w/electric cord 6* # 240388701 A B C...
-
Page 10: Wiring Schematic
Publication No. FRT18P5A 5995379723 WIRING SCHEMATIC 10/02... -
Page 11: Wiring Diagram
FRT18P5A Publication No. 5995379723 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
