Hanna Instruments HI 9564 Instruction Manual

Instruction Manual
HI 9564 - HI 9565
Portable
Water-Resistant
Thermo-Hygrometers
w w w . h a n n a i n s t . c o m
WARRANTY
All Hanna Instruments meters are warranted for two years against defects in workmanship and
materials when used for their intended purpose and maintained according to instructions.
Probes are warranted for a period of six months.
This warranty is limited to repair or replacement free of charge.
Damage due to accidents, misuse, tampering or lack of prescribed maintenance are not covered.
If service is required, contact the dealer from whom you purchased the instrument. If under warranty,
report the model number, date of purchase, serial number and the nature of the problem. If the repair is
not covered by the warranty, you will be notified of the charges incurred. If the instrument is to be
returned to Hanna Instruments, first obtain a Returned Goods Authorization Number from the Customer
Service department and then send it with shipment costs prepaid.
When shipping any instrument, make sure it is properly packaged for complete protection.
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the
copyright owner.
Recommendations for Users
Before using these products, make sure that they are entirely suitable for the environment in which they are used.
Operation of these instruments in residential area could cause unacceptable interferences to radio and TV
equipment, requiring the operator to take all necessary steps to correct interferences.
Any variation introduced by the user to the supplied equipment may degrade the instruments' EMC performance.
To avoid electrical shock, do not use these instruments when voltages at the measurement surface exceed 24VAC or
60 VDC. To avoid damages or burns, do not perform any measurement in microwave ovens.
Dear Customer,
Thank you for choosing a Hanna product.
This manual will provide you with the necessary information for the correct operation of
the meter. Please read it carefully before using the meter.
If you need additional technical information, do not hesitate to e-mail us at
tech@hannainst.com.
These instruments are in compliance with the directives.
PRELIMINARY EXAMINATION
Remove the instrument from the packing material and examine it carefully to make sure
that no damage has occurred during shipment. If there is any damage, notify your
Dealer.
Both models come supplied with:
• HI 70602 RH/temperature probe
• 9V battery
• instruction manual.
Note: Save all packing material until the instrument has been observed to function
correctly. Any defective item must be returned in its original packing.
GENERAL DESCRIPTION
HI 9564 and HI 9565 are portable thermo-hygrometers for measurements of Temperature
and Relative Humidity. HI 9565 also shows the dewpoint calculated from the measured
Temperature and Relative Humidity.
The instruments are housed in a rugged, water-resistant casing for maximum protection
against effect of humidity and condensation.
The RH/temperature probe is a "smart probe" which contains the sensors, electronic sensor
drive circuitry and memory to store the calibration information. This allows interchange-
ability between probes and meters without recalibration.
Note: The RH probe sensor must never come into contact with water or other liquids.
Hanna Instruments reserves the right to modify the design, construction and appearance of its products
without advance notice.
FUNCTIONAL DESCRIPTION
SPECIFICATIONS
Range 20.0 to 95.0 % RH
0.0 to 60.0°C / 32.0 to 140.0°F (*)
-20.0 to 60.0°C / -4.0 to 140.0°F
dewpoint (HI 9565 only)
Resolution 0.1 % RH / 0.1°C / 0.1°F
dewpoint (HI 9565 only) 0.1°C / 0.1°F
Accuracy
±3 % RH (50 to 85 % RH & 15 to 40°C); ±5% RH (outside)
±0.5°C / ±1°F
dewpoint (HI 9565 only) ±2°C /±4°F (50 to 85 % RH & 15 to 40°C); ±4.5°C /±9°F (outside)
Typical EMC Dev. ±1 % RH
±0.5°C / ±1°F
±0.5°C / ±1°F
dewpoint (HI 9565 only)
Probe (included) HI 70602 RH/temperature probe
Battery Type 1 x 9V alkaline (IEC 6LR61)
Battery Life 250 hours of continuous use
Auto-off after 20 minutes of non use
Environment 0 to 60°C (32 to 122°F); 98% RH non-condensing
Dimensions 164 x 76 x 45 mm (6.5 x 3.0 x 1.8")
Weight 340 g (12 oz.)
(*)
Note: The meter measures temperature from -30 to 80°C, but the RH measurement can only be
taken within the range 0 to 60 °C.
