Use & Care Guide
Model: 7116572
Char-Broil
FOP
®

Natural Gas Conversion Kit

This Natural Gas Conversion Kit can be used ONLY with
Dual Fuel™ grills.
If you have questions or need assistance during assembly, please call
1-800-241-7548 (USA) or 1-800-387-6057 (Canada)
To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7116572 Instr and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Char-Broil 7116572 Instr

Summary of Contents for Char-Broil 7116572 Instr

  • Page 1: Natural Gas Conversion Kit

    Use & Care Guide Model: 7116572 Char-Broil ® Natural Gas Conversion Kit This Natural Gas Conversion Kit can be used ONLY with Dual Fuel™ grills. If you have questions or need assistance during assembly, please call 1-800-241-7548 (USA) or 1-800-387-6057 (Canada)

  • Page 2: Warning & Cautions

    DANGER WARNING CALIFORNIA PROPOSITION 65 If you smell gas: 1. Combustion by-products produced when using 1. Shut off gas to the appliance. this product contain chemicals known to the State of 2. Extinguish any open flame. California to cause cancer, birth defects, and other reproductive harm.

  • Page 3: Table Of Contents

    CONNECTING YOUR GRILL TO THE NATURAL GAS SOURCE: TABLE OF CONTENTS 1. A professionally-installed shut-off valve between the supply Warning & Cautions ........2 piping and the socket is recommended, but not required, by the National Fuel Gas Code.

  • Page 4: Use And Care

    The appliance and its individual shut off valve must be USE AND CARE CON’T. disconnected from the gas supply piping system during any pressure testing on that system at test pressures in excess of 1/2 psig (3.5kPa). The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5kPa).

  • Page 5: Grill Matrix

    Model 415.16135110 Model 415.16649011 Model 415.16138110 415.16167210 Model 415.16139110 415.16164210 415.16139111...

  • Page 6: Section A

    Section A First, make sure all Control Knobs are in the OFF position, LP tank valve is closed, and Tank is disconnected from Regulator and removed from Grill. Next, open Lid and remove Warming Rack, Cooking Grates, and Heat Diffusers. Your Grill may differ from illustrations shown.
  • Page 7 Position Natural Gas Hose Assembly behind cart up to Manifold Connection. Secure the Natural Gas Hose Assembly, to Manifold Connection, using a wrench (not provided). Manifold Connection Natural Gas Hose Assembly Leak Testing Natural Gas Hose Turn all grill knobs to OFF. Brush soapy solution onto areas where bubbles are shown in picture.

  • Page 8: Section B

    Section B Remove Hitch Pins and remove Carryover Tubes. Remove Hitch Pins at back of Burners to detach Burners from Burner Brackets. Lift back of Burner while sliding Burner out of Firebox, disengaging burners from Valves. Burner Hitch Pin Front of Firebox Hitch Pin Carryover Tube...
  • Page 9 Section B Con’t. WARNING Bezels must be replaced one at a time. Removing more than one bezel at a time may cause misalignment of manifold. Pull the Tube Burner Control Knob off of Valve Stem. Remove two Screws and two Washers that secure Bezel to the Control Panel. Save removed Bezel for converting back to LP Tank Gas.

  • Page 10: Section C

    Section C Remove Hitch Pins and remove Carryover Tubes. Remove Hitch Pins at back of Burners to detach Burners from Burner Brackets. Lift back of Burner while sliding Burner out of Firebox, disengaging burners from Valves. Burner Hitch Pin Front of Firebox Hitch Pin Burner...
  • Page 11 Section C Con’t. Remove two Screws, two Lock Washers and two Flat Washers at the back of Searing Burner. Slide Searing Burner back and up to remove Burner. Lock Washer Screw Flat Washer Searing Burner Insert Orifice Driving Tool into Firebox Burner openings and unscrew Orifice from end of Valve. Save removed orifice for converting back to LP Tank Gas.
  • Page 12 Section C Con’t. WARNING Bezels must be replaced one at a time. Removing more than one bezel at a time may cause misalignment of manifold. Pull the Tube Burner Control Knob off of Valve Stem. Remove two Screws and two Washers that secure Bezel to the Control Panel. Save removed Bezel for converting back to LP Tank Gas.

  • Page 13: Section D

    Section D Remove Screws, Washers, and Nuts that secure Rotisserie Cover to back of grill Firebox. Remove Rotisserie Cover. Screw Flat Washer Lock Washer Using a wrench (not provided) remove Securing Nut from Rotisserie Connector. Slide Rotisserie Connector out from Rotisserie Burner Tube Rotisserie Securing...
  • Page 14 Section D Con’t. Using Orifice Driving Tool provided with Kit, unscrew Orifice from Rotisserie Connector. Save Orifice for converting back to LP Tank Gas. Do not mix with Orifices removed from Main Burners. For Grill Model 415.16649011 replace with Natural Gas Orifice 1.45mm (Red Dot) and secure tightly to Rotisserie Connector. For Grill Model 415.16139110 replace with Natural Gas Orifice #53 (Yellow Dot) and secure tightly to Rotisserie Connector.

  • Page 15: Section E

    Section D Con’t. Pull the Rotisserie Control Knob off of Valve Stem. Remove screws and washers that secure Bezel to the Control Panel. Save removed Bezel for converting back to LP Tank Gas. Install new Natural Gas Bezel provided with Kit (see illustration below) in place of old Bezel onto Control Panel, and secure using previously removed screws and washers.
  • Page 16 Section E Con’t. Remove two Screws at the back of Sideburner. Remove Sideburner from Shelf. Screws From inside the Shelf unscrew Orifice from end of Sideburner valve using the Orifice Driving Tool provided with kit. Save Orifice for converting back to LP Tank Gas. Do not mix with Orifices removed from Tube Burners. DO NOT replace the Orifice.
  • Page 17 Section E Con’t. Pull the Sideburner Control Knob off of Valve Stem. Remove the existing Bezel by removing the two Screws and two Washers securing Bezel to Shelf fascia. Save removed Bezel for converting back to LP Tank Gas. Install new Natural Gas Bezel (see illustration below) and press Control Knob back onto Valve Stem. Bezel Screw Valve stem...

  • Page 18: Section F

    Section E Con’t. Slide Sideburner Electrode into Collector Box. Secure Sideburner Electrode to Sideburner with Screw. Replace Sideburner Cooking Grate. Screw Collector box Sideburner cooking grate Sideburner Electrode Sideburner Electrode Reinstall Heat Diffusers, Cooking Grates and Warming Rack, reference illustration Section A1. for reinstallation. Section F Open Sideburner Lid and remove the Sideburner Grate.
  • Page 19 Section F Con’t. Using the provided Orifice Driving Tool, unscrew the Orifice from the end of the Sideburner Valve. Save removed Orifice and Orifice Driving Tool for converting back to LP. DO NOT replace the Orifice. This Valve is designed to work with Natural Gas once Orifice is removed. Orifice Driving Tool Pull the Sideburner Control Knob off of Valve Stem.

  • Page 20: Section G

    Section F Con’t. Return Sideburner to Shelf. Make sure Burner engages Sideburner Valve. See illustration below for correct burner-to-valve engagement. Secure Burner to Shelf with Wingnut. Place Sideburner Grate onto Sideburner Pan. Sideburner Grate Sideburner Sideburner Wingnut Reinstall Heat Diffusers, Cooking Grates and Warming Rack, reference illustration Section A1. for reinstallation. Sideburner Grate Section G Open Sideburner Lid and remove the Sideburner Grate.
  • Page 21 Section G Con’t. Using the provided Orifice Driving Tool, unscrew the Orifice from the end of the Sideburner Valve. Save removed Orifice and Orifice Driving Tool for converting back to LP. Replace Orifice with Natural Gas Orifice # 53 (Yellow Dot) and secure tightly to Sideburner Valve. Orifice Yellow Dot Orifice Driving Tool...

  • Page 22: Troubleshooting

    Section G Con’t. Return Sideburner to Shelf. Make sure Burner engages Sideburner Valve. See illustration below for correct burner-to-valve engagement. Secure Burner to Shelf with two Washers and two Screws. Reconnect Ignitor wire to Electrode. Place Sideburner Grate onto Sideburner Pan. Sideburner Grate Sideburner Electrode...
  • Page 23 This page is intentionally blank...
