CONVERSION KIT
This Natural Gas Conversion Kit can be used ONLY with
If you have questions or need assistance during assembly, please call 1-800-241-7548
WARNING
•
Read and follow all Safety Assembly
and Use and Care Instructions in this
Guide before assembling and cooking
with this grill.
•
Failure to follow all instructions in this
Use and Care Guide may lead to fire or
,
explosion which could result in property
,
damage personal injury or death
