User Manual
For use with Chamberlain 315 MHz or 390 MHz garage door
openers manufactured after January 1, 1993. The garage door
opener activates when the 4-digit Personal Identification Number
(PIN) and ENTER button are pressed on the Keyless Entry.
Install the battery and program the Keyless Entry prior to
installation. Make sure the garage door opener has a working
light bulb because it is a programming indicator.
PREPARE
3
Enter a 4-digit
personal
identification
number (PIN)
of your choice:
? ? ? ?
To program the Keyless Entry to more than one garage door opener, repeat the steps above using a new PIN for each additional garage door opener.
CHANGE AN EXISTING PIN*
1
Press the programmed PIN
that you want to change.
? ? ? ?
*
For garage door openers that have a green Learn button or an external receiver repeat "Program Initial PIN" to change the existing PIN.
®
To prevent possible SERIOUS INJURY or DEATH from a moving gate or garage door:
• Install Keyless Entry Control within sight of the garage door, out of reach of children at a minimum height of 5 feet (1.5 m), and
away from ALL moving parts of door.
• ALWAYS keep remote controls out of reach of children. NEVER permit children to operate, or play with remote controls.
• Activate gate or door ONLY when it can be seen clearly, is properly adjusted, and there are no obstructions to door travel.
• ALWAYS keep gate or garage door in sight until completely closed. NEVER permit anyone to cross path of moving gate or door.
Locate the Learn button on the
garage door opener.
NOTE: Your garage door opener may
look different.
Learn
LED
OR
OR
Learn
LED
Green
or
Purple
Red/Orange
4
Press and release the ENTER
button...
Check to see if the
light bulb blinks.
If not, slowly
press and release
the ENTER button
until the light bulb
blinks. Be careful NOT to
press the ENTER button after the
light bulb blinks.
2
Press and hold the
# button until...
...the light bulb
blinks twice.
WIRELESS KEYLESS ENTRY • MODELS 940EV AND 940EVC
PROGRAM INITIAL PIN
1
Learn
LED
Yellow
5
3
Enter the new 4-digit PIN of your choice,
then press the ENTER button.
+
? ? ? ?
new PIN
2
Press and hold
the
and #
*
buttons until
the lights on the
keypad stop
blinking.
6
To test, press the PIN, then press the ENTER button.
Press 0 to
complete the
programming.
+
? ? ? ?
PIN
The light bulb will blink once.
Press and
release the
Learn button.
The LED will light.
Within 30 seconds...
The garage door
opener will activate.
4
To test, press the new PIN,
then the ENTER button.
The garage door opener
will activate.
