Before installation

Before installation
Note
Be sure to disconnect the battery's negative terminal before
installing the receiver.

Components

No.
1 Main unit
2 Mounting sleeve
3 Side bracket
4 Rear bracket
5 Bezel
6 Bushing
7 Self-tapping screw (6 x 16 mm)
8 Stud bolt
9 Flat head screw (5 x 8 mm)
10 Hex-head bolt (5 x 20 mm)
11 Hex nut (5 mm)
12 Interconnecting cable
13 Remote control

Setting the system-selector switch

When this receiver is used in combination with an external amplifier,
DSP, etc., the selector switch on the left side of the main unit may
have to be switched.
Set the switch according to the table below:
External amplifier
None
None
Connected
Connected
* : Pattern of selector switch at shipping
MAIN UNIT LEFT SIDE VIEW
Item
DSP/EQ/XOVER
None
Connected
Connected
None
86
Q'ty
1
1
2
1
1
1
2
1
4
2
2
1
1
Switch
OFF*
ON
OFF*
OFF*
