Frigidaire FRS6R5EM Parts Catalog

Frigidaire FRS6R5EM Parts Catalog

R134a series
Hide thumbs Also See for FRS6R5EM:
Table of Contents

Advertisement

Quick Links

N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAA0.eps
N58SJCAAB12.eps N58TAAAAA6.eps N58CAAAAA5.eps N58XDAAAA1.eps
N58YBAAAA0.eps N58I115.eps W241526901A.eps S241526901A.eps
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS6R5EMB2 FRS6R5EMB4 FRS6R5EMB6
Series
R134a
Color
silver mist
Volts
115
Wiring Diagram
241526901
Owner's Guide
241661500
Market
North America North America North America
Energy Guide
241585980
Service Data Sheet 240389616
Publication No.
5995445078
05/08/18
(EN/SERVICE/KHB)
137
R134a
R134a
silver mist
silver mist
115
115
241526901
241526901
241661500
241661500
241585980
241585980
240389616
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6R5EM
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS6R5EM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS6R5EM

Summary of Contents for Frigidaire FRS6R5EM

  • Page 1 Product No. FRS6R5EMB2 FRS6R5EMB4 FRS6R5EMB6 Series R134a R134a R134a Color silver mist silver mist silver mist Volts Wiring Diagram 241526901 241526901 241526901 Owner's Guide 241661500 241661500 241661500 Market North America North America North America Energy Guide 241585980 241585980 241585980 Service Data Sheet 240389616 240389616 240389616 SIDE-BY-SIDE...

  • Page 2: Freezer Door

    Publication No: 5995445078 FRS6R5EM FREEZER DOOR N58FCCBBB2 08/05...
  • Page 3 FRS6R5EM Publication No: 5995445078 FREEZER DOOR Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 241569806 A B C Gasket-frzr door, black, magnetic 240334201 A B C Bin-door, frzr-upper 240351601 A B C Bin-door 241526758 A B -...

  • Page 4: Refrigerator Door

    Publication No: 5995445078 FRS6R5EM REFRIGERATOR DOOR N58RCCBBB5 08/05...
  • Page 5 FRS6R5EM Publication No: 5995445078 REFRIGERATOR DOOR Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 241569805 A B C Gasket-refr door, black, magnetic 240323001 A B C Bin-door, pseudo, bottom 240326203 A B C Door-dairy 240581905 A B C...
  • Page 6 Publication No: 5995445078 FRS6R5EM CABINET 08/05...
  • Page 7 FRS6R5EM Publication No: 5995445078 CABINET Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 240435906 A B C Cover-air duct 240475907 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 240505801 A B C Switch, light/lamp...
  • Page 8 Publication No: 5995445078 FRS6R5EM SHELVES N58SJCAAB12 08/05...
  • Page 9 FRS6R5EM Publication No: 5995445078 SHELVES Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 241657602 A B C Shelf, flip up, wire 241657502 A B C Shelf, fixed, freezer 241657504 A B C Shelf, fixed, freezer 240355208 A B C...
  • Page 10 Publication No: 5995445078 FRS6R5EM CONTROLS N58TAAAAA6 08/05...
  • Page 11 FRS6R5EM Publication No: 5995445078 CONTROLS Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg, (2)
  • Page 12 Publication No: 5995445078 FRS6R5EM SYSTEM N58CAAAAA5 08/05...
  • Page 13 FRS6R5EM Publication No: 5995445078 SYSTEM Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 5303305677 A B C Drier-filter, R12 & R134a 241586801 A B C Harness-wiring, machine compt...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995445078 FRS6R5EM ICE & WATER DISPENSER 08/05...
  • Page 15 FRS6R5EM Publication No: 5995445078 ICE & WATER DISPENSER Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976904 A B C Tube-water inlet, valve to filter...

  • Page 16: Ice Container

    Publication No: 5995445078 FRS6R5EM ICE CONTAINER 08/05...
  • Page 17 FRS6R5EM Publication No: 5995445078 ICE CONTAINER Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 218815400...

  • Page 18: Ice Maker

    Publication No: 5995445078 FRS6R5EM ICE MAKER 08/05...
  • Page 19 FRS6R5EM Publication No: 5995445078 ICE MAKER Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976904 A B C Tube-water inlet, valve to filter 218976907 A B C...
  • Page 20 Publication No: 5995445078 FRS6R5EM ICE MAKER 08/05...
  • Page 21 FRS6R5EM Publication No: 5995445078 ICE MAKER Model Index: A FRS6R5EM (FRS6R5EMB2) B FRS6R5EM (FRS6R5EMB4) C FRS6R5EM (FRS6R5EMB6) POS. NO PART NO. DESCRIPTION 218709100 A B C Screw, hex head, 10-32 x 0.500 240363601 A B C Screw-shoulder 240542901 A B C Cap-water valve 5303207328 A B C...

  • Page 22: Wiring Schematic

    Publication No: 5995445078 FRS6R5EM WIRING SCHEMATIC 08/05...

  • Page 23: Wiring Diagram

    FRS6R5EM Publication No: 5995445078 WIRING DIAGRAM 08/05 # Functional Parts * Non-Illustrated Parts...
