Frigidaire FRT18KC3B Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT18KC3B:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT18KC3BW0
FRT18KC3B
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
white
Publication No.
5995367710
020307
-EN/SERVICE/DCS
390
FACTORY
PARTS CATALO
VOLTS
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18KC3B
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18KC3B
Summary of Contents for Frigidaire FRT18KC3B
- Page 1 PRODUCT NO. BASE MODEL NO. FRT18KC3BW0 FRT18KC3B MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379007 ELECTROLUX HOME PRODUCTS, INC P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a white...
- Page 2 Publication No. FRT18KC3B0 5995367710 DOOR 03/02...
- Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT18KC3B0 DOOR PART NO DESCRIPTION 240514605 Gasket-frzr door, white, magnetic 240514606 Gasket-refr door, white, magnetic 240331401 Rack-door,20.27" x 1.72" 240311502 Support-door rack,2 liter ,RH 240331502 Support-door rack,gallon ,RH 240311501 Support-door rack,2 liter ,LH 240331501 Support-door rack,gallon ,LH 240337703...
- Page 4 Publication No. FRT18KC3B0 5995367710 CABINET 03/02...
- Page 5 POS. NO 10*# 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KC3B0 CABINET PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462005 Cover-evap coil 240371302 Seal,insulation ,47.77 in.
- Page 6 Publication No. FRT18KC3B0 5995367710 SHELVES 03/02...
- Page 7 POS. NO 17*# 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KC3B0 SHELVES PART NO DESCRIPTION 215667501 Tray-ice,plastic 5303282284 Shelf-freezer,"table type" 240362502 Diffuser-air,top 240362601 Diffuser-air,bottom 240392601 Seal-diffuser 240505801 Switch,light/lamp 240436701 Light Bulb/Lamp, A-15, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240352701...
- Page 8 Publication No. FRT18KC3B0 5995367710 SYSTEM 03/02...
- Page 9 POS. NO 6* # 6* # 14 # 15 # 21 # 29 # 30 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRT18KC3B0 SYSTEM PART NO DESCRIPTION 240406401 Condenser,static 240405201 Grommet,rubber ,black ,cond tube/wire 5303208866 Spacer-cond tube,black 5308000296 Bracket,condenser mtg ,(4) 5308009617...
-
Page 10: Wiring Schematic
Publication No. FRT18KC3B0 5995367710 WIRING SCHEMATIC 03/02... -
Page 11: Wiring Diagram
FRT18KC3B0 Publication No. 5995367710 WIRING DIAGRAM # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
