Frigidaire FRT18B5A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18B5A
  6. Factory parts catalog
Frigidaire FRT18B5A Factory Parts Catalog

Frigidaire FRT18B5A Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT18B5A:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT18B5AB7
FRT18B5A
FRT18B5AQ7
FRT18B5A
FRT18B5AT7
FRT18B5A
FRT18B5AW7
FRT18B5A
FRT18B5AZ7
FRT18B5A
MARKET
North America
WIRING DIAGRAM - 240379010
OWNER'S GUIDE - 240400107
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995380085
021023
-EN/SERVICE /DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18B5A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18B5A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18B5A

Summary of Contents for Frigidaire FRT18B5A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18B5AB7 FRT18B5A R134a black FRT18B5AQ7 FRT18B5A R134a bisque FRT18B5AT7 FRT18B5A R134a bisque FRT18B5AW7 FRT18B5A R134a white FRT18B5AZ7 FRT18B5A R134a white MARKET North America WIRING DIAGRAM - 240379010 OWNER’S GUIDE - 240400107 SERVICE DATA SHEET - # 240379010 TOP MOUNT REFRIGERATOR...
