Frigidaire FRT18B6C Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18B6C
  6. Factory parts catalog
Frigidaire FRT18B6C Factory Parts Catalog

Frigidaire FRT18B6C Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT18B6C:

Advertisement

Quick Links

Download this manual
N05L00002.eps N05DCDBCA1.eps N05BBAABA6.eps N05SAADDA11.eps
N05CABBAB4.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRT18B6CB7
Series
R134a
Color
black
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400111
Market
North America
Energy Guide
240572124
Service Data Sheet
240379014
Installation Instructions 240568300
Publication No.
5995411807
04/06/21
(EN/SERVICE/WC)
390
Copyright
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18B6C
©
2004 Home Pr
oducts, Inc.
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18B6C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT18B6C

Summary of Contents for Frigidaire FRT18B6C

  • Page 1 Product No. FRT18B6CB7 Series R134a Color black Volts Wiring Diagram 240398801 Owner's Guide 240400111 Market North America Energy Guide 240572124 Service Data Sheet 240379014 Installation Instructions 240568300 TOP-MOUNT N05L00002.eps N05DCDBCA1.eps N05BBAABA6.eps N05SAADDA11.eps REFRIGERATOR N05CABBAB4.eps 240398801.eps 240398601.eps ELECTROLUX HOME PRODUCTS, INC. Model No.
  • Page 2 Publication No: 5995411807 FRT18B6CB7 DOOR 06/04...
  • Page 3 FRT18B6CB7 Publication No: 5995411807 DOOR POS. NO PART NO. DESCRIPTION 240514609 Gasket, frzr door seal, black, magnetic 240514612 Gasket, seal, black, refr door, magnetic 240337701 Door-dairy, w/o graphics, white 240381303 Plug-button, black, hinge brg hole 240476203 Panel-frzr door, black, complete assy 240415204 Label-nameplate, black 240312405...
  • Page 4 Publication No: 5995411807 FRT18B6CB7 CABINET 06/04...
  • Page 5 FRT18B6CB7 Publication No: 5995411807 CABINET POS. NO PART NO. DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 240367401 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 240462010 Cover-evap coil 240568605 Seal-coil cover 5303208309 Plug-hole, factory test 13 #...
  • Page 6 Publication No: 5995411807 FRT18B6CB7 SHELVES 06/04...
  • Page 7 FRT18B6CB7 Publication No: 5995411807 SHELVES POS. NO PART NO. DESCRIPTION 215667501 Tray, ice cube, plastic 5303282284 Shelf-freezer, "table type" 240362502 Diffuser, air, top 240362601 Diffuser, air, bottom 14 # 241554901 Switch-light/lamp 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240352701...
  • Page 8 Publication No: 5995411807 FRT18B6CB7 SYSTEM N05CABBAB4 06/04...
  • Page 9 FRT18B6CB7 Publication No: 5995411807 SYSTEM POS. NO PART NO. DESCRIPTION 240444401 Condenser, dynamic 218944001 Drier-filter, R134a System 240581701 Harness-wiring, machine compt 6* # 240388701 Wiring Harness, control box 6* # 240524701 Wiring Harness, freezer section 14 # 5303918208 Defrost Heater Kit 15 # 5303918274 Evaporator Kit...

  • Page 10: Wiring Schematic

    Publication No: 5995411807 FRT18B6CB7 WIRING SCHEMATIC 06/04...

  • Page 11: Wiring Diagram

    FRT18B6CB7 Publication No: 5995411807 WIRING DIAGRAM 06/04 # Functional Parts * Non-Illustrated Parts...
