Frigidaire FRT18B5A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18B5A
  6. Factory parts catalog
Frigidaire FRT18B5A Factory Parts Catalog

Frigidaire FRT18B5A Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT18B5A:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT18B5AQ1
FRT18B5A
FRT18B5AW1
FRT18B5A
MARKET
North America
WIRING DIAGRAM - 240379009
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - # 240379009
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995366423
020220
-EN/SERVICE/DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18B5A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18B5A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT18B5A

Summary of Contents for Frigidaire FRT18B5A

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT18B5AQ1 FRT18B5A FRT18B5AW1 FRT18B5A MARKET North America WIRING DIAGRAM - 240379009 OWNER’S GUIDE - 240400105 SERVICE DATA SHEET - # 240379009 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 SERIES COLOR R134a bisque...
