Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
PLRH1779GS0
Series
Twins
Color
black-s/s
Volts
115
Wiring Diagram 297005300
Owner's Guide 297208700
Market
North America
Energy Guide
297115903
Publication No.
5995508776
08/03/14
(EN/SERVICE/MLR)
365
Copyright
REFRIGERATOR
Model No.
PLRH1779GS
©
2008 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire PLRH1779GS
Summary of Contents for Frigidaire PLRH1779GS
- Page 1 Product No. PLRH1779GS0 Series Twins Color black-s/s Volts Wiring Diagram 297005300 Owner's Guide 297208700 Market North America Energy Guide 297115903 REFRIGERATOR P08F0092.eps P08D0547.eps P08C1091.eps P08S0479.eps Model No. Electrolux Major Appliances PLRH1779GS North & Latin America P.O. BOX 212378 AUGUSTA, GA 30917 Publication No.
- Page 2 Publication No: 5995508776 PLRH1779GS0 DOOR P08D0547 03/08...
- Page 3 PLRH1779GS0 Publication No: 5995508776 DOOR POS. NO PART NO. DESCRIPTION 216522311 Gasket-door, black 240338313 Door, dairy, clear 216953601 Panel-inner door, refr 216526560 Panel-outer door, stainless 241808801 Label-nameplate 5303271076 Door Stop 240536818 Handle-door, stainless steel, with insert, & set screw 5304460608 Screw, flat head, #1/4-20, door stop/hng 216524200 Gasket, secondary...
- Page 4 Publication No: 5995508776 PLRH1779GS0 CABINET 148B 148A P08C1091 03/08...
- Page 5 PLRH1779GS0 Publication No: 5995508776 CABINET POS. NO PART NO. DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 297200600 Breaker Kit w/corners, no lock slot 297200100 Breaker Kit w/corners, 32", top and bottom 13 # 216934100 Motor, fan, 115 V 216998100 Switch, light/lamp, black, ramp 216988100 Light Bulb/Lamp, long, blue tint, 40 W, 120V 297048600...
- Page 6 Publication No: 5995508776 PLRH1779GS0 CABINET 148B 148A P08C1091 03/08...
- Page 7 PLRH1779GS0 Publication No: 5995508776 CABINET POS. NO PART NO. DESCRIPTION 148A 297092502 Frame-crisper cover, lower 148B 297092503 Frame-deli cover 216974600 Bearing, hinge closer 297053000 Wire, jumper 5303313703 Clip, (2) 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2) 297092700 Bracket, crisper cover, RH 297092701...
- Page 8 Publication No: 5995508776 PLRH1779GS0 SYSTEM 141A P08S0479 03/08...
