Frigidaire PLRU1778ES Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. PLRU1778ES
  6. Factory parts catalog
Frigidaire PLRU1778ES Factory Parts Catalog

Frigidaire PLRU1778ES Factory Parts Catalog

Twins series
Hide thumbs Also See for PLRU1778ES:
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual See also: Use and Care Manual
P08F0072.eps P08D0562.eps P08C1111.eps P08S0472.eps
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
PLRU1778ES4
Series
Twins
Color
black-s/s
Volts
115
Wiring Diagram 297005300
Owner's Guide 297081600
Market
North America
Energy Guide
216697904
Publication No.
5995517835
08/06/26
(EN/SERVICE/MLR)
365
Copyright
REFRIGERATOR
Model No.
PLRU1778ES
©
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PLRU1778ES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire PLRU1778ES

Summary of Contents for Frigidaire PLRU1778ES

  • Page 1 Product No. PLRU1778ES4 Series Twins Color black-s/s Volts Wiring Diagram 297005300 Owner's Guide 297081600 Market North America Energy Guide 216697904 REFRIGERATOR P08F0072.eps P08D0562.eps P08C1111.eps P08S0472.eps Model No. P.O. BOX 212378 PLRU1778ES AUGUSTA, GA 30917 Publication No. 5995517835 08/06/26 (EN/SERVICE/MLR) © Copyright All rights reserved.
  • Page 2 Publication No: 5995517835 PLRU1778ES4 DOOR P08D0562 06/08...
  • Page 3 PLRU1778ES4 Publication No: 5995517835 DOOR POS. NO PART NO. DESCRIPTION 216522311 Gasket-door, black 240338313 Door, dairy, clear 216953600 Panel-inner door, refr 297245224 Panel-outer door, stainless 240558802 Nameplate, door badge, stainless 297257000 Door Stop, chrome, RH/LH 240536818 Handle-door, stainless steel, with insert, & set screw 218755402 Screw-set, 10-32 x 0.375 218755504...
  • Page 4 Publication No: 5995517835 PLRU1778ES4 CABINET 138A 138A 138A 139A 138B 138A 137A P08C1111 06/08...
  • Page 5 PLRU1778ES4 Publication No: 5995517835 CABINET POS. NO PART NO. DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 297200600 Breaker Kit w/corners, no lock slot 297200100 Breaker Kit w/corners, 32", top and bottom 13 # 216934100 Motor, fan, 115 V 216998100 Switch, light/lamp, black, ramp 216988100 Light Bulb/Lamp, long, blue tint, 40 W, 120V 297048600...
  • Page 6 Publication No: 5995517835 PLRU1778ES4 CABINET 138A 138A 138A 139A 138B 138A 137A P08C1111 06/08...
  • Page 7 PLRU1778ES4 Publication No: 5995517835 CABINET POS. NO PART NO. DESCRIPTION 138B 297050701 Trim-shelf, front 297050800 Trim-shelf, rear 139A 297050801 Trim-shelf, rear 216995501 Cover-crisper pan 240361301 Damper, humidity cont. 240361202 Knob, humidity cont. 216988200 Support-crspr cover, RH 216988201 Support-crspr cover, LH 297053000 Wire, jumper 5303313703...
  • Page 8 Publication No: 5995517835 PLRU1778ES4 SYSTEM 06/08...
  • Page 9 PLRU1778ES4 Publication No: 5995517835 SYSTEM POS. NO PART NO. DESCRIPTION 297152200 Condenser, dynamic 5308000110 Strap-evap/heater, aluminum, (2) 216938600 Drier-filter 297171800 Harness-main 240555002 Screw-#8-32 X 3/8 297048400 Clip 216730700 Heater-defrost 15 # 216997300 Evaporator 297231800 Heat Exchanger 297078700 Insulator-evap, styrofoam 297078800 Insulator-evap, styrofoam 216731001 Thermostat, defrost...
