Frigidaire PLRU1778ES Factory Parts Catalog
Twins series
Hide thumbs
Also See for PLRU1778ES:
- Factory parts catalog (9 pages) ,
- Use and care manual (10 pages) ,
- Use and care manual (10 pages)
Advertisement
Quick Links
Download this manual
See also:
Use and Care Manual
P08F0080.eps P08D0457.eps P08C1068.eps P08S0461.eps
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
PLRU1778ES1
Series
Twins
Color
S/S-Black
Volts
115
Wiring Diagram 297005300
Owner's Guide 297081600
Market
North America
Energy Guide
216697904
Publication No.
5995505202
08/01/11
(EN/SERVICE/MLR)
365
Copyright
REFRIGERATOR
Model No.
PLRU1778ES
©
All rights reserved.
Advertisement
Related Manuals for Frigidaire PLRU1778ES
Summary of Contents for Frigidaire PLRU1778ES
- Page 1 Product No. PLRU1778ES1 Series Twins Color S/S-Black Volts Wiring Diagram 297005300 Owner's Guide 297081600 Market North America Energy Guide 216697904 REFRIGERATOR P08F0080.eps P08D0457.eps P08C1068.eps P08S0461.eps Model No. P.O. BOX 212378 PLRU1778ES AUGUSTA, GA 30917 Publication No. 5995505202 08/01/11 (EN/SERVICE/MLR) © Copyright All rights reserved.
