Masonry acid washing materials
S
All fuel- -burning equipment must be supplied with air for fuel
combustion. Sufficient air must be provided to avoid negative
pressure in the equipment room or space. A positive seal must be
made between the furnace cabinet and the return- -air duct to
prevent pulling air from the burner area and from draft safeguard
opening.
Fig. 5 - - Installation in a Garage
WARNING
!
ELECTRICAL OPERATION HAZARD
Failure to follow this warning could result in personal
injury, death, and/or property damage.
When the furnace is installed in a residential garage, the
burners and ignition sources must be located at least 18
inches above the floor. The furnace must be located or
protected to avoid damage by vehicles. When the furnace is
installed in a public garage, airplane hangar, or other
building having a hazardous atmosphere, the furnace must
be installed in accordance
CAN/CSA- -B149.1- -05. (See Fig. 5).
Table 2 – Minimum Free Area Required for Each Combustion Air Opening or Duct to Outdoors
TWO HORIZONTAL DUCTS
(1 SQ. IN./2,000 BTUH)
FUR-
(1,100 SQ. MM/KW)
NACE
INPUT
Free Area of Opening
(BTUH)
and Duct
(sq. in. / sq. mm)
44,000 22 (14193)
66,000 33 (21290)
88,000 44 (28387)
110,000 55 (35484)
132,000 66 (42581)
FURNACE WATER HEATER
110,000 + 30,000
66,000 + 40,000
88,000 + 30,000
18-IN. (457.2 mm)
MINIMUM TO BURNERS
A93044
with the NFGC or
SINGLE DUCT OR OPENING
(1 SQ. IN./3,000 BTUH)
Round Duct Free Area of Open-
Diameter ing and Duct
(in./mm) (sq. In. / sq. mm)
6 (152) 14.7 (9484)
7 (178) 22 (14193)
8 (203) 29.3 (18903)
9 (229) 36.7 (23677)
10 (254) 44 (28387)
EXAMPLES: Determining Free Area
TOTAL INPUT
= (140,000 divided by 4,000)
= (106,000 divided by 3,000)
= (118,000 divided by 2,000)
CAUTION
!
PERSONAL INJURY AND/OR PROPERTY
DAMAGE HAZARD
Improper use or installation of this furnace may cause
premature furnace component failure.
This gas furnace may be used for heating buildings under
construction provided that:
- -The furnace is permanently installed with all electrical
wiring, piping, venting and ducting installed according to
these installation instructions. A return air duct is provided,
sealed to the furnace casing, and terminated outside the
space containing the furnace. This prevents a negative
pressure condition as created by the circulating air blower,
causing a flame rollout and/or drawing combustion
products into the structure.
- -The furnace is controlled by a thermostat. It may not be
"hot wired" to provide heat continuously to the structure
without thermostatic control.
- -Clean outside air is provided for combustion. This is to
minimize the corrosive effects of adhesives, sealers and
other construction
entrainment of drywall dust into combustion air, which can
cause fouling and plugging of furnace components.
- -The temperature of the return air to the furnace is
maintained between 55_F (13_C) and 80_F (27_C), with
no evening setback or shutdown. The use of the furnace
while the structure is under construction is deemed to be
intermittent operation per our installation instructions.
- -The air temperature rise is within the rated rise range on
the furnace rating plate, and the gas input rate has been set
to the nameplate value.
- -The filters used to clean the circulating air during the
construction process must be either changed or thoroughly
cleaned prior to occupancy.
- -The furnace, ductwork and filters are cleaned as necessary
to remove drywall dust and construction debris from all
HVAC system components after construction is completed.
- -Verify proper furnace operating conditions including
ignition, gas input rate, air temperature rise, and venting
according to these installation instructions.
(734 SQ. MM/KW)
Round Duct
Diameter
(in. / mm)
5 (127)
6 (152)
7 (178)
7 (178)
8 (203)
= 35.0 Sq. In. for each two Vertical Ducts or Openings
= 35.3 Sq. In. for a Single Duct or Opening
= 59.0 Sq. In. for each of two Horizontal Ducts
