Product No.
FRTB7B4EMB2
Series
beverage center
Color
silver mist
Volts
115
Wiring Diagram
240398801
Owner's Guide
241695500
Market
North America
Service Data Sheet 240379018
Publication No.
5995489324
07/04/20
(EN/SERVICE/KHB)
390
Copyright
TOP-MOUNT
REFRIGERATOR
Model No.
FRTB7B4E
©
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRTB7B4E
Summary of Contents for Frigidaire FRTB7B4E
- Page 1 Product No. FRTB7B4EMB2 Series beverage center Color silver mist Volts Wiring Diagram 240398801 Owner's Guide 241695500 Market North America Service Data Sheet 240379018 TOP-MOUNT N05L00015.eps N05DDDCMA1.eps N05BBAABA25.eps N05SADAJY2.eps REFRIGERATOR N05CAABAD1.eps 240398801.eps 240398601.eps P.O. BOX 212378 Model No. AUGUSTA, GA 30917 FRTB7B4E Publication No.
- Page 2 Publication No: 5995489324 FRTB7B4EMB2 DOOR 503A N05DDDCMA1 04/07...
- Page 3 FRTB7B4EMB2 Publication No: 5995489324 DOOR POS. NO PART NO. DESCRIPTION 240542119 Gasket-frzr door, black, magnetic 240542122 Gasket, refr door seal, black, magnetic 240535101 Rack-door 240535201 Rack-door 240535001 Rack-door 240381303 Plug-button, black, hinge brg hole 240433503 Door-frzr, silver mist, complete assy 241808601 Label-nameplate 240312405...
- Page 4 Publication No: 5995489324 FRTB7B4EMB2 CABINET N05BBAABA25 04/07...
- Page 5 FRTB7B4EMB2 Publication No: 5995489324 CABINET POS. NO PART NO. DESCRIPTION 241652301 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 241523701 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 241652215 Cover-evap coil 240568601 Seal-coil cover 10*# 241520701 Harness-wiring, freezer...
- Page 6 Publication No: 5995489324 FRTB7B4EMB2 SHELVES N05SADAJY2 04/07...
- Page 7 FRTB7B4EMB2 Publication No: 5995489324 SHELVES POS. NO PART NO. DESCRIPTION 240358004 Shelf, freezer 241542001 Diffuser, air, top 240362601 Diffuser, air, bottom 14 # 241554901 Switch-light/lamp 241555401 Light Bulb 241559801 Socket-light 240368001 Control Box 240568607 Seal 17*# 240388701 Wiring Harness, control box 240360801 Knob, temp control 21 #...
- Page 8 Publication No: 5995489324 FRTB7B4EMB2 SYSTEM 24 25 N05CAABAD1 04/07...
- Page 9 FRTB7B4EMB2 Publication No: 5995489324 SYSTEM POS. NO PART NO. DESCRIPTION 241682902 Condenser, dynamic 218944001 Drier-filter, R134a System 241607001 Harness-wiring, machine compt 240388701 Wiring Harness, control box 241520701 Harness-wiring, freezer 14 # 240356213 Heater-defrost 15 # 5303918275 Evaporator Kit 5308000110 Strap-evap/heater, aluminum, (2) 241801302 Trough-drain 241551901...
-
Page 10: Wiring Schematic
Publication No: 5995489324 FRTB7B4EMB2 WIRING SCHEMATIC 04/07... -
Page 11: Wiring Diagram
FRTB7B4EMB2 Publication No: 5995489324 WIRING DIAGRAM 04/07 # Functional Parts * Non-Illustrated Parts...
