Use and Care Manual
PRODUCT NO.
BASE MODEL NO.
FRT18SJGD2
FRT18SJG
FRT18SJGW2
FRT18SJG
MARKET
North America
WIRING DIAGRAM - # 218758400
OWNER'S GUIDE - # 218613700
SERVICE DATA SHEET - # 218758400
101 MASTERS BLVD.
ANDERSON, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
Publication No.
5995316584
990106
-EN/SERVICE /ECL
390
REFRIGERATOR
VOLTS
115
115
REFRIGERATOR
Model No.
FRT18SJG
©1999 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT18SJG
Summary of Contents for Frigidaire FRT18SJG
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18SJGD2 FRT18SJG R134a System almond FRT18SJGW2 FRT18SJG R134a System white MARKET North America WIRING DIAGRAM - # 218758400 OWNER’S GUIDE - # 218613700 SERVICE DATA SHEET - # 218758400 REFRIGERATOR Model No.
- Page 2 Publication No. FRT18SJG 5995316584 DOOR 01/99...
- Page 3 FRT18SJG Publication No. 5995316584 DOOR A = FRT18SJG (FRT18SJGD2) B = FRT18SJG (FRT18SJGW2) POS. NO PART NO DESCRIPTION 215608906 Gasket-frzr door,almond ,magnetic 215608916 Gasket-frzr door,white ,magnetic 218730606 Gasket-refr door,almond ,magnetic 218730605 Gasket-refr door,white ,magnetic 218360701 Panel-inner door,refr 218758602 Support-door rack,RH/LH 5303308341 Door-dairy,12.96"...
- Page 4 Publication No. FRT18SJG 5995316584 CABINET 01/99...
- Page 5 FRT18SJG Publication No. 5995316584 CABINET A = FRT18SJG (FRT18SJGD2) B = FRT18SJG (FRT18SJGW2) POS. NO PART NO DESCRIPTION 218672501 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 218448302 Cover,almond ,lwr hinge hole 218448301 Cover,white ,lwr hinge hole 5300157666 Bushing-motor mtg,(2) 5303205118...
- Page 6 Publication No. FRT18SJG 5995316584 SHELVES 01/99...
- Page 7 FRT18SJG Publication No. 5995316584 SHELVES A = FRT18SJG (FRT18SJGD2) B = FRT18SJG (FRT18SJGW2) POS. NO PART NO DESCRIPTION 218874311 Mullion,almond ,1 218874301 Mullion,white ,1 218781003 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2) 218814800 Panel-top,refr cavity 5303001380 Screw,truss head ,8-10 x 1.750 218872903 Divider,styrofoam ,w/foil tape 218878500...
- Page 8 Publication No. FRT18SJG 5995316584 SYSTEM 01/99...
- Page 9 FRT18SJG Publication No. 5995316584 SYSTEM A = FRT18SJG (FRT18SJGD2) B = FRT18SJG (FRT18SJGW2) POS. NO PART NO DESCRIPTION 218173900 Condenser 5308000296 Bracket,condenser mtg ,(4) 5308009617 Washer,ext tooth lock ,#10 218541000 Drier-filter 218878500 Harness-wiring,control/divider 215257004 Harness-wiring,compressor 5316254901 Cord-electric power 5303001197 Cover-wiring 13 # 218429306 Heat Exchanger,suction line...
