Frigidaire FRT21S6A Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT21S6A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
N05L00003.eps N05DCDBCA1.eps N05BBAABA17.eps N05SABAFI17.eps
N05CAAAAA25.eps
240398801.eps 240398601.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
THIS CATALOG SUPERCEDES
5995469672.
Product No.
FRT21S6ABC FRT21S6AQC FRT21S6AWC
Series
R134a
Color
black
Volts
115
Wiring Diagram
240398801
Owner's Guide
241694400
Market
North America North America North America
Service Data Sheet
240379018
Installation Instructions 240568301
Publication No.
5995478277
06/11/02
(EN/SERVICE/KHB)
137
R134a
R134a
bisque
white
115
115
240398801
240398801
241694400
241694400
240379018
240379018
240568301
240568301
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21S6A
©
Copyright
2006 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT21S6A
Summary of Contents for Frigidaire FRT21S6A
- Page 1 Product No. FRT21S6ABC FRT21S6AQC FRT21S6AWC Series R134a R134a R134a Color black bisque white Volts Wiring Diagram 240398801 240398801 240398801 Owner's Guide 241694400 241694400 241694400 Market North America North America North America Service Data Sheet 240379018 240379018 240379018 Installation Instructions 240568301 240568301 240568301 TOP-MOUNT...
- Page 2 Publication No: 5995478277 FRT21S6A DOOR N05DCDBCA1 11/06...
- Page 3 FRT21S6A Publication No: 5995478277 DOOR Model Index: A FRT21S6A (FRT21S6ABC) B FRT21S6A (FRT21S6AQC) C FRT21S6A (FRT21S6AWC) POS. NO PART NO. DESCRIPTION 240514611 A - - Gasket, seal, black, frzr door, magnetic 240514607 - B C Gasket, seal, white, frzr door, magnetic 240514612 A - - Gasket, seal, black, refr door, magnetic...
- Page 4 Publication No: 5995478277 FRT21S6A CABINET N05BBAABA17 11/06...
- Page 5 FRT21S6A Publication No: 5995478277 CABINET Model Index: A FRT21S6A (FRT21S6ABC) B FRT21S6A (FRT21S6AQC) C FRT21S6A (FRT21S6AWC) POS. NO PART NO. DESCRIPTION 240355402 A B C Cover-fan 240367001 A B C Knob-damper control 5303212803 A B C 241523701 A B C Damper-fan cover 5308000010 A B C...
- Page 6 Publication No: 5995478277 FRT21S6A CABINET N05BBAABA17 11/06...
- Page 7 FRT21S6A Publication No: 5995478277 CABINET Model Index: A FRT21S6A (FRT21S6ABC) B FRT21S6A (FRT21S6AQC) C FRT21S6A (FRT21S6AWC) POS. NO PART NO. DESCRIPTION 5304455655 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin 241733907 A B C Cover-access, with label 241500303 A B C Screw, hex washer head, 8-18AB x 0.500...
- Page 8 Publication No: 5995478277 FRT21S6A SHELVES 11/06...
- Page 9 FRT21S6A Publication No: 5995478277 SHELVES Model Index: A FRT21S6A (FRT21S6ABC) B FRT21S6A (FRT21S6AQC) C FRT21S6A (FRT21S6AWC) POS. NO PART NO. DESCRIPTION 215667501 A B C Tray, ice cube, plastic 240358006 A B C Shelf, freezer, full-width, wire 5303299664 A B C Spacer, shelf 240545901 A B C...
- Page 10 Publication No: 5995478277 FRT21S6A SYSTEM N05CAAAAA25 11/06...
- Page 11 FRT21S6A Publication No: 5995478277 SYSTEM Model Index: A FRT21S6A (FRT21S6ABC) B FRT21S6A (FRT21S6AQC) C FRT21S6A (FRT21S6AWC) POS. NO PART NO. DESCRIPTION 240444401 A B C Condenser, dynamic 5303305677 A B C Drier-filter, R12 & R134a 241607001 A B C Harness-wiring, machine compt 6* # 240388701 A B C...
-
Page 12: Wiring Schematic
Publication No: 5995478277 FRT21S6A WIRING SCHEMATIC 11/06... -
Page 13: Wiring Diagram
FRT21S6A Publication No: 5995478277 WIRING DIAGRAM 11/06 # Functional Parts * Non-Illustrated Parts...
