Elkay Celebrity GECR3321 Specifications

SPECIFICATIONS

GENERAL
Designed and recommended for use with GE undersink
dishwasher. Good quality Celebrity double bowl sink is
formed of #20 gauge, type 304 (18-8) nickel bearing stainless
steel. Self-rimming.
DESIGN FEATURES
Bowl Depth: 5-3/8".
Coved Corners: 3" vertical radius, 2-1/4" horizontal radius.
Bowl and Faucet Deck Recess: 3/16" below outside edge of
sink.
Finish: Exposed surfaces are machine polished to a bright
Celebrity finish.
Underside: Fully undercoated to dampen sound and prevent
condensation.
OTHER
Drain opening: 3-1/2" as illustrated.
Note: Unless otherwise specified, sink is furnished with 4
faucet holes as illustrated.
This sink complies with ASME Standard A112.19.3.
This sink is listed by the International Association of
Plumbing and Mechanical Officials as meeting the
requirements of the Uniform Plumbing Code.
OPTIONAL ACCESSORIES
Cutting Board: CB1516.
Rinsing Baskets: LKWRB1316SS, LKWERBSS.
Utensil Caddy for Rinsing Basket: LKWUCSS.
Bottom Grid: LKWOBG1415SS.
Drain Fitting: LK35L.
SINK DIMENSIONS (INCHES)*
Overall Inside Each Bowl
Model
Number L W
GECR3321 33 21 1 / 14 15
4
*
Length is left to right. Width is front to back
2-1/4" 4" 4"
14"
33"
2-1/4"R
Model GECR33214 Illustrated
THIS PRODUCT, AS CONSTRUCTED IS SUBJECT TO INTERPRETATION OF A.D.A. REQUIREMENTS.
THE UNOBSTRUCTED KNEE SPACE REQUIRED TO SATISFY A.D.A. STANDARDS MAY NOT BE DESIRABLE.
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
elkayusa.com
®
Cutout in
Countertop
(1 1 / " Radius
2
Corners)
L W D L W
3 / 5 3 / 32 3 / 20 5 / 1, 2, MR2, 3, 4 or 5
4 8 8 8
.
4"
3-3/4"
4-3/4"
15-3/4"
21-1/4"
3"R
14"
5-3/8"
2222 Camden Court
Oak Brook, IL 60523
Model GECR3321 – A.D.A. Compliant
No. of
1 1 / " Dia.
2
Faucet Minimum
Holes Cabinet
4" Centers Size
36
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Celebrity ® Double Bowl Sink
Model GECR33214
HOLE DRILLING
CONFIGURATIONS
1
4"
2
4"
MR2
4" 4"
3
4" 4"
4
4" 4" 4"
5
Printed in U.S.A.
©2007 Elkay
(Rev. 7/07)
4"
4"
1-26C
