Elkay Celebrity DCR252210 Specifications

SPECIFICATIONS

GENERAL

Good quality Celebrity single bowl is seamlessly drawn of #20
gauge, type 304 (18-8) nickel bearing stainless steel. Self-
rimming. Exclusive trimmed corner design.

DESIGN FEATURES

Bowl Depth: 10".
Coved Corners: 3" vertical radius, 1-3/4" horizontal radius.
Bowl and Faucet Deck Recess: 3/16" total recess below out-
side edge of sink.
Finish: Exposed surfaces are machine polished to a highlighted
finish.
Underside: Fully undercoated to prevent condensation and
deaden sound.

OTHER

Drain Opening: 3-1/2".
Faucet Holes: 1, 2, 3, 4 or 5, 1-1/2" faucet holes as indicated,
4" center to center.
NOTE: Unless otherwise specified, sink is furnished with 3 faucet
holes.

OPTIONAL ACCESSORIES

Rinsing Baskets: LKRB2015 and LKERBSS.
Cutting Board: CB1516.

SINK DIMENSIONS (INCHES)*

Overall
Model
Number L W
DCR252210 25 22
*
Length is left to right. Width is front to back
4" 4"
3" R
21"
25"
1-3/4" R
Model DCR2522103 Illustrated
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
Cutout in
Countertop
1
(1 / " Radius
2
Inside Bowl Corners)
L W D L W
21 15 3 / 10 24 3 / 21 3 /
4 8 8
.
22"
15-3/4"
10"
2222 Camden Court
Oak Brook, IL 60523
20 Gauge – Type 304 – Self-Rim
No. of
1 1 / " Dia.
2
Faucet Minimum Ship.
Holes Cabinet Wt.
4" Center Size Lbs.
1, 2, 3, 4 or 5 30 14 1 /
2
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Celebrity ® Single Bowl Sink
Model DCR252210
Model DCR2522103
Printed in U.S.A.
©2003 Elkay
(Rev. 11/03)
1-16D
