Frigidaire FRT21INLH Factory Parts Catalog
R134a system series
Hide thumbs
Also See for FRT21INLH:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
PRODUCT NO.
BASE MODEL NO.
FRT21INLHB1
FRT21INLH
FRT21INLHD1
FRT21INLH
FRT21INLHW1
FRT21INLH
MARKET
North America
WIRING DIAGRAM - #193832
OWNER'S GUIDE - # 218972200
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
black
R134a System
almond
R134a System
white
Publication No.
5995332060
000119
-EN/SERVICE /DJH
357
REFRIGERATOR
VOLTS
115
115
115
REFRIGERATOR
Model No.
FRT21INLH
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21INLH
Summary of Contents for Frigidaire FRT21INLH
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21INLHB1 FRT21INLH R134a System black FRT21INLHD1 FRT21INLH R134a System almond FRT21INLHW1 FRT21INLH R134a System white MARKET North America WIRING DIAGRAM - #193832 OWNER’S GUIDE - # 218972200 SERVICE DATA SHEET - # 218755000 REFRIGERATOR Model No.
- Page 2 Publication No. FRT21INLH 5995332060 DOOR 01/00...
- Page 3 FRT21INLH Publication No. 5995332060 DOOR A = FRT21INLH (FRT21INLHW1) B = FRT21INLH (FRT21INLHD1) C = FRT21INLH (FRT21INLHB1) POS. NO PART NO DESCRIPTION 215608913 A B - Gasket-frzr door,white ,magnetic 215608923 - - C Gasket-frzr door,black ,magnetic 218730609 A B - Gasket-refr door,white ,magnetic 218730622 - - C...
- Page 4 Publication No. FRT21INLH 5995332060 CABINET 01/00...
- Page 5 FRT21INLH Publication No. 5995332060 CABINET A = FRT21INLH (FRT21INLHW1) B = FRT21INLH (FRT21INLHD1) C = FRT21INLH (FRT21INLHB1) POS. NO PART NO DESCRIPTION 5304402655 A B C Cover-fan 5303307351 A B C Knob-damper control 5303001028 A B C Nut,push-on 218722200 A B C Damper-fan cover,black 218649000 A B C...
- Page 6 Publication No. FRT21INLH 5995332060 CABINET 01/00...
- Page 7 FRT21INLH Publication No. 5995332060 CABINET A = FRT21INLH (FRT21INLHW1) B = FRT21INLH (FRT21INLHD1) C = FRT21INLH (FRT21INLHB1) POS. NO PART NO DESCRIPTION 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile 5308000107 A B C Bracket-connector 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875 215099701...
- Page 8 Publication No. FRT21INLH 5995332060 SHELVES 01/00...
- Page 9 FRT21INLH Publication No. 5995332060 SHELVES A = FRT21INLH (FRT21INLHW1) B = FRT21INLH (FRT21INLHD1) C = FRT21INLH (FRT21INLHB1) POS. NO PART NO DESCRIPTION 218651900 A - - Mullion,white 218651901 - B - Mullion,almond 218651902 - - C Mullion,black 218781002 A B C Heater-mullion 218845602 A B C...
- Page 10 Publication No. FRT21INLH 5995332060 SYSTEM 01/00...
- Page 11 FRT21INLH Publication No. 5995332060 SYSTEM A = FRT21INLH (FRT21INLHW1) B = FRT21INLH (FRT21INLHD1) C = FRT21INLH (FRT21INLHB1) POS. NO PART NO DESCRIPTION 218657100 A B C Condenser 5304406039 A B C Spacer-tube,5/8 OD x 3" lg 5304406040 A B C Spacer-tube,5/8 OD x 12"...
-
Page 12: Ice Maker
Publication No. FRT21INLH 5995332060 ICE MAKER 01/00... - Page 13 FRT21INLH Publication No. 5995332060 ICE MAKER A = FRT21INLH (FRT21INLHW1) B = FRT21INLH (FRT21INLHD1) C = FRT21INLH (FRT21INLHB1) POS. NO PART NO DESCRIPTION 5314368805 A B C Tube-valve to IM,plastic ,cut to length 3206348 A B C Spring,shut-off arm 3206299 A B C Plate-I.D.
-
Page 14: Wiring Schematic
Publication No. FRT21INLH 5995332060 WIRING SCHEMATIC 01/00... -
Page 15: Wiring Diagram
FRT21INLH Publication No. 5995332060 WIRING DIAGRAM # = Fast-moving Parts 01/00 * = Non-Illustrated Parts...
