Frigidaire FRT21IS6B Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT21IS6B
  6. Factory parts catalog
Frigidaire FRT21IS6B Factory Parts Catalog

Frigidaire FRT21IS6B Factory Parts Catalog

Top mount refrigerator r134a series
Hide thumbs Also See for FRT21IS6B:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21IS6BB3
FRT21IS6B
FRT21IS6BB4
FRT21IS6B
FRT21IS6BQ3
FRT21IS6B
FRT21IS6BQ4
FRT21IS6B
FRT21IS6BW3
FRT21IS6B
FRT21IS6BW4
FRT21IS6B
MARKET
North America
WIRING DIAGRAM - # 240379012
OWNER'S GUIDE - # 240400110
SERVICE DATA SHEET - # 240379012
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995398723
031111
-EN/SERVICE /DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21IS6B
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21IS6B and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT21IS6B

Summary of Contents for Frigidaire FRT21IS6B

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT21IS6BB3 FRT21IS6B FRT21IS6BB4 FRT21IS6B FRT21IS6BQ3 FRT21IS6B FRT21IS6BQ4 FRT21IS6B FRT21IS6BW3 FRT21IS6B FRT21IS6BW4 FRT21IS6B MARKET North America WIRING DIAGRAM - # 240379012 OWNER’S GUIDE - # 240400110 SERVICE DATA SHEET - # 240379012 ELECTROLUX HOME PRODUCTS, INC P.O.
  • Page 2 Publication No. FRT21IS6B 5995398723 DOOR 11/03...
  • Page 3 A = FRT21IS6B (FRT21IS6BB3) B = FRT21IS6B (FRT21IS6BB4) C = FRT21IS6B (FRT21IS6BQ3) D = FRT21IS6B (FRT21IS6BQ4) E = FRT21IS6B (FRT21IS6BW3) F = FRT21IS6B (FRT21IS6BW4) POS. NO PART NO 240514611 240514607 240514612 240514608 240337703 240381303 240381302 240381301 240450312 240450306 240450302 240416304...
  • Page 4 Publication No. FRT21IS6B 5995398723 CABINET 11/03...
  • Page 5 A = FRT21IS6B (FRT21IS6BB3) B = FRT21IS6B (FRT21IS6BB4) C = FRT21IS6B (FRT21IS6BQ3) D = FRT21IS6B (FRT21IS6BQ4) E = FRT21IS6B (FRT21IS6BW3) F = FRT21IS6B (FRT21IS6BW4) POS. NO PART NO 240355402 240367001 5303001028 240367401 5308000010 5300157666 5303292396 240313610 240568606 10*# 240524701 5303208309...
  • Page 6 Publication No. FRT21IS6B 5995398723 SHELVES 11/03...
  • Page 7 A = FRT21IS6B (FRT21IS6BB3) B = FRT21IS6B (FRT21IS6BB4) C = FRT21IS6B (FRT21IS6BQ3) D = FRT21IS6B (FRT21IS6BQ4) E = FRT21IS6B (FRT21IS6BW3) F = FRT21IS6B (FRT21IS6BW4) POS. NO PART NO 240358003 240545901 240362601 14 # 240505801 240436702 241500701 240368101 17*# 240388701 240360801...
  • Page 8 Publication No. FRT21IS6B 5995398723 SYSTEM 11/03...
  • Page 9 A = FRT21IS6B (FRT21IS6BB3) B = FRT21IS6B (FRT21IS6BB4) C = FRT21IS6B (FRT21IS6BQ3) D = FRT21IS6B (FRT21IS6BQ4) E = FRT21IS6B (FRT21IS6BW3) F = FRT21IS6B (FRT21IS6BW4) POS. NO PART NO 240444401 218944001 240581701 6* # 240388701 6* # 240524701 6* # 240581801...

  • Page 10: Ice Maker

    Publication No. FRT21IS6B 5995398723 ICE M AKER 11/03...
  • Page 11 A = FRT21IS6B (FRT21IS6BB3) B = FRT21IS6B (FRT21IS6BB4) C = FRT21IS6B (FRT21IS6BQ3) D = FRT21IS6B (FRT21IS6BQ4) E = FRT21IS6B (FRT21IS6BW3) F = FRT21IS6B (FRT21IS6BW4) POS. NO PART NO 218976901 5304420650 5308000039 3206299 3206301 3206303 3206305 3206306 3206312 3206313 3206315 11 #...

  • Page 12: Wiring Schematic

    Publication No. FRT21IS6B 5995398723 WIRING SCHEMATIC 11/03...

  • Page 13: Wiring Diagram

    FRT21IS6B Publication No. 5995398723 WIRING DIAGRAM # = Fast-moving Parts 11/03 * = Non-Illustrated Parts...
