Elkay Elite Gourmet 4826EGT Specifications

SPECIFICATIONS

GENERAL
Elite Gourmet Sink can be customized with optional backsplash,
faucet, cabinet or front panel and towel bar.
SINK DESIGN FEATURES
Material: Hand fabricated and finished from professional grade
Type 304 stainless steel: 16 gauge sink deck with 18 gauge bowls.
Length: Standard 48".
Bowl Depth: 7-1/2" Left and Right, 5-1/8" Center Disposer.
Coved Corners: 1-3/4" Horizontal and 3" Vertical Radius.
Outer edge of sink has a 5/32" raised rim.
Underside: Fully protected by heavy duty Sound Guard
coating to prevent condensation and deaden sound.
Hand blended and finished stainless steel surface featuring a
highlighted inside top bowl radius.
Drain Fittings: (3) LK99 drains included.
Choice of front treatment: Bullnose or Square. Square front
comes with towel bar mounting holes.
Sinks come standard with backsplash mounting holes. Specify
"WB" suffix to order without.
Backsplash: For design features, reference specification sheet
EG-5.
Cabinet: For design features, reference specification sheet EG-4.
Front Panel: Included with cabinet. If cabinet is not required,
front panel is available as a separate component. Reference spec-
ification sheet EG-4.
Towel Bar: Choice of chrome or chrome with gold accent finish.
Attached to front panel when combined with bullnose front
treatment sinks. With square front treatment sinks, towel bar is
attached to sink and not to the front panel.
Faucets: For design features, reference specification sheets, EG-7
and EG-8.
OPTIONAL ACCESSORIES
LKH180/190 Series Instant Hot Water Dispensers
LK2156 Series Instant Cold Water Dispensers
ERS1 Remote Chiller
SINK DIMENSIONS (INCHES)*
Model
Overall
Number
L W L
4826EGTB 48 26 16 17
4826EGTS 48 26 16 17
*
Length is left to right. Width is front to back
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
Elkay
www.elkayusa.com
®
™ under-
LK313 Series Soap Dispensers
LKRB1611 and LKRB715 Rinse Baskets
CB816 Cutting Board
Right Center Left
Bowl Bowl Bowl
W D L W D L
1 / 7 1 / 7 1 / 15 3 / 5 16 17
2 2 2 4
1 1 1 3
/ 7 / 7 / 15 / 5 16 17
2 2 2 4
.
2222 Camden Court
Oak Brook, IL 60523
Triple Bowl Sink
shown with Bullnose Front,
optional Front Panel, Towel Bar
and Rectangular 3/4" Backsplash
Fits
Front Cabinet
W D Treatment Base
1 / 7 1 / 2" Bullnose 48"
2 2
1 1
/ 7 / 2" Square 48"
2 2
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elite Gourmet
48" TRIPLE BOWL SINK
Models 4826EGT
No. of 1-1/2" Dia. Faucet
Holes. 2 Hole at 8" Centers,
3 and 4 Hole at 4" Centers.
0 Hole Std. w/ 2" Backsplash
0, 2, 3 or 4
0, 2, 3 or 4
Printed in U.S.A.
©2003 Elkay
(Rev. 4/03)
™ by Elkay
EG-3B
