PRODUCT NO.
BASE MODEL NO.
FRT18RRJD0
FRT18RRJ
FRT18RRJW0
FRT18RRJ
MARKET
North American
WIRING DIAGRAM - #193832
OWNER'S GUIDE - # 218972200
SERVICE DATA SHEET - # 218758400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
almond
R134a System
white
Publication No.
5995332946
000208
-EN/SERVICE/KHB
390
REFRIGERATOR
VOLTS
115
115
REFRIGERATOR
Model No.
FRT18RRJ
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT18RRJ
Summary of Contents for Frigidaire FRT18RRJ
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18RRJD0 FRT18RRJ R134a System almond FRT18RRJW0 FRT18RRJ R134a System white MARKET North American WIRING DIAGRAM - #193832 OWNER’S GUIDE - # 218972200 SERVICE DATA SHEET - # 218758400 REFRIGERATOR Model No.
- Page 2 Publication No. FRT18RRJ 5995332946 DOOR 02/00...
- Page 3 FRT18RRJ Publication No. 5995332946 DOOR A = FRT18RRJ (FRT18RRJD0) B = FRT18RRJ (FRT18RRJW0) POS. NO PART NO DESCRIPTION 215608916 Gasket-frzr door,white ,magnetic 218730605 Gasket-refr door,white ,magnetic 218360001 Panel-inner door,refr 218763639 Rack-door,20.81" x 2.04" 218809801 Support-door rack,RH 218758602 Support-door rack,RH/LH 218809701 Support-door rack,LH 218287908 Door-dairy,10.71"...
- Page 4 Publication No. FRT18RRJ 5995332946 CABINET 02/00...
- Page 5 FRT18RRJ Publication No. 5995332946 CABINET A = FRT18RRJ (FRT18RRJD0) B = FRT18RRJ (FRT18RRJW0) POS. NO PART NO DESCRIPTION 218672501 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 3206451 Cover-evap coil 5303209814 Nut,"U"...
- Page 6 Publication No. FRT18RRJ 5995332946 SHELVES 02/00...
- Page 7 FRT18RRJ Publication No. 5995332946 SHELVES A = FRT18RRJ (FRT18RRJD0) B = FRT18RRJ (FRT18RRJW0) POS. NO PART NO DESCRIPTION 218874311 Mullion,almond 218874301 Mullion,white 218781003 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2) 218814800 Panel-top,refr cavity 218872903 Divider,styrofoam ,w/foil tape 218878500 Wiring Harness,control/divider 218814700 Panel-bottom,frzr cavity 215667501 Tray-ice,plastic...
- Page 8 Publication No. FRT18RRJ 5995332946 SYSTEM 02/00...
- Page 9 FRT18RRJ Publication No. 5995332946 SYSTEM A = FRT18RRJ (FRT18RRJD0) B = FRT18RRJ (FRT18RRJW0) POS. NO PART NO DESCRIPTION 218173900 Condenser 5303208866 Spacer-cond tube,black 5308000296 Bracket,condenser mtg ,(4) 5308009617 Washer,ext tooth lock ,#10 ,grounding 218944001 Drier-filter,R134a System 218878500 Wiring Harness,control/divider 215257004 Wiring Harness,compressor 5316254901 Cord-electric power...
-
Page 10: Wiring Schematic
Publication No. FRT18RRJ 5995332946 WIRING SCHEMATIC 02/00... -
Page 11: Wiring Diagram
FRT18RRJ Publication No. 5995332946 WIRING DIAGRAM # = Fast-moving Parts 02/00 * = Non-Illustrated Parts...
